Maxim Integrated Operational Amplifier, 85 MHz Gain Bandwidth Product, 4 Channel, 14-Pin SOIC Package, 4.5-11V MAX4395ESD+
Specifications
| Country of Origin | India |
|---|---|
| Brand | Maxim Integrated |
| Height | 1.5mm |
| Length | 8.75mm |
| Model | MAX4395ESD+ |
| Width | 4mm |
| Mount Type | Surface |
| Output Current | 75mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pin Count | 14 |
| Maximum Supply Voltage | 11V |
| Minimum Supply Voltage | 4.5V |
| GBP - Gain Bandwidth Product | 85MHz |
| Input Bias Current | 15 μA |
| Vos - Input Offset Voltage | 26 mV |
| Slew Rate | 500V/μs |
| Input Offset Current | 5 μA |
Key Features
- The amplifier provides a high slew rate of 500 V/μs for fast signal response.
- Input offset voltage is low, rated at 26 mV, ensuring precision amplification.
- Input bias current is 15 μA, suitable for various electronic designs.
- Operating temperature ranges from -40°C to 85°C, ensuring reliability in harsh environments.
- Output current capability is 75 mA per channel for driving loads effectively.
- Compact SOIC package measures 8.75 mm length, 4 mm width, and 1.5 mm height.
- The product complies with RoHS standards for environmental safety.
Product Description
Maxim Integrated MAX4395ESD+ is a high-performance operational amplifier designed for demanding electronic applications requiring wide bandwidth and fast slew rates. Featuring four independent channels within a single 14-pin SOIC surface-mount package, this device provides versatility for multi-channel analog amplification.
Operating from a low minimum supply voltage of 4.5V up to 11V maximum, the MAX4395ESD+ supports a gain bandwidth product of 85 MHz, facilitating high-speed signal processing in instrumentation, communication, and audio systems.
The amplifier’s low input offset voltage of 26 mV and input bias current of 15 μA enable precise and stable signal amplification, making it suitable for sensitive measurement and control applications. It maintains reliable operation over a wide temperature range of -40°C to 85°C, suitable for automotive, industrial, and consumer electronics.
The device can deliver an output current of up to 75 mA per channel, allowing it to drive moderate loads efficiently. Its SOIC package dimensions of 8.75 mm (length), 4 mm (width), and 1.5 mm (height) make it an excellent choice for compact printed circuit board designs.
Designed with compliance to RoHS standards, this operational amplifier ensures reduced environmental impact. High gain bandwidth product of 85 MHz supports high-speed amplification. Four independent amplifier channels in a single SOIC package.
Wide supply voltage range from 4.5V to 11V for flexible power options. Low input offset voltage and bias current for accuracy. Wide operating temperature range supports harsh environments. Capable of delivering 75 mA output current per channel.
Compact SOIC surface-mount package optimizes board space. RoHS compliant, environmentally safe component. This operational amplifier is ideal for industrial, automotive, laboratory, and electronic manufacturing uses where precision, speed, and reliability are critical.
Explore related Operational Amplifiers and semiconductor components on EnvMart for integrated electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 85 MHz, enabling high-speed signal processing.
This model can deliver an output current of up to 75 mA per channel, allowing it to drive moderate loads effectively.
The operational amplifier operates within a temperature range of -40°C to 85°C, making it suitable for harsh environments.
The input offset voltage is rated at 26 mV, which helps ensure precision amplification.
The SOIC package measures 8.75 mm in length, 4 mm in width, and 1.5 mm in height, optimizing board space.
This operational amplifier features four independent channels, providing versatility for multi-channel analog amplification.
The input bias current is 15 μA, suitable for various electronic designs.
The minimum supply voltage is 4.5V, and the maximum supply voltage is 11V, allowing for flexible power options.
The amplifier provides a high slew rate of 500 V/μs, which contributes to fast signal response.
Yes, this operational amplifier complies with RoHS standards for environmental safety.
The country of origin for the MAX4395ESD+ is India.
This operational amplifier uses surface mount technology, making it suitable for compact printed circuit board designs.
