Microchip Dual Operational Amplifier 14 kHz Gain Bandwidth, 8-Pin SOIC 6V MCP6042T-I/SN
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.5mm |
| Length | 4.9mm |
| Model | MCP6042T-I/SN |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | MCP6042 |
| Output Current | 30mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 1.4V |
| GBP - Gain Bandwidth Product | 14kHz |
| Input Bias Current | 1 pA |
| Vos - Input Offset Voltage | ±3 mV |
| Slew Rate | 3V/ms |
| Wide supply voltage range | 1.4V to 6.0V |
| Gain bandwidth product | 14 kHz (typical) |
| Low Quiescent Current | 600 nA/amplifier (typical) |
Key Features
- This amplifier offers low quiescent current of 600 nA per amplifier, ensuring energy efficiency.
- Rail-to-rail input and output provide full voltage swing for enhanced performance.
- Operating supply voltage ranges from 1.4V to 6V for versatile applications.
- It features a low input offset voltage typically less than ±3 mV for precision amplification.
- The device is unity gain stable, simplifying use in multiple configurations.
- Suitable for industrial process control, low-power battery-operated, and portable equipment.
- Compact dimensions of 4.9 mm length, 3.9 mm width, and 1.5 mm height allow easy PCB integration.
- Compliant with RoHS standards ensuring environmental safety and reduced hazardous substances.
Product Description
Microchip MCP6042T-I/SN is a dual operational amplifier designed for precision analog signal processing with a gain bandwidth product of 14 kHz and rail-to-rail input/output capability. This device operates from a single supply voltage ranging from 1.4V to 6V, making it suitable for low power and portable electronic applications.
The MCP6042 features extremely low quiescent current of 600 nA per amplifier, minimizing power consumption while maintaining high performance with an input offset voltage typically under ±3 mV. The operational amplifier is unity gain stable, allowing for straightforward use in voltage follower configurations.
Its compact 8-pin SOIC surface-mount package measures 4.9 mm in length, 3.9 mm in width, and 1.5 mm in height, facilitating integration into densely populated PCBs. The device supports output currents up to 30 mA, suitable for a wide range of load requirements. It is RoHS compliant to ensure environmental safety and compliance with international standards.
The MCP6042 is ideal for industrial process control equipment, battery-operated instruments, portable devices, and wearables due to its low power, wide voltage supply range, and robust performance over a temperature range of -40°C to 85°C. Its advanced CMOS technology ensures high open-loop gain and low bias currents for precision analog applications.
This amplifier has a gain bandwidth product of 14 kHz. Low typical quiescent current of 600 nA per amplifier. Rail-to-rail input and output operation. Wide single supply voltage range from 1.4V to 6.0V. Unity gain stable for flexible circuit design.
Available in compact 8-pin SOIC surface mount package. Maximum output current of 30 mA per channel. Operating temperature range from -40°C to +85°C. RoHS compliant manufacturing standard.
This dual Operational Amplifier expands options for analog signal conditioning in electronics manufacturing and laboratory instrumentation. Whether in industrial automation or consumer electronics, the MCP6042 ensures stable and accurate amplification with minimal power draw.
Explore the range of Microchip amplifiers and related components at EnvMart for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 14 kHz, which is typical for its performance.
It operates within a supply voltage range of 1.4V to 6V, allowing for versatile applications in low-power environments.
The MCP6042T-I/SN can deliver a maximum output current of 30 mA per channel, suitable for various load requirements.
This operational amplifier has compact dimensions of 4.9 mm in length, 3.9 mm in width, and 1.5 mm in height.
The typical input offset voltage is less than ±3 mV, ensuring precision in amplification.
It is available in an 8-pin SOIC surface-mount package, facilitating easy integration into PCBs.
The quiescent current is typically 600 nA per amplifier, contributing to its low power consumption.
The operational amplifier can function within an operating temperature range of -40°C to +85°C.
Yes, this device is compliant with RoHS standards, ensuring reduced hazardous substances and environmental safety.
It is suitable for industrial process control, low-power battery-operated devices, and portable equipment due to its performance characteristics.
The slew rate of the MCP6042T-I/SN is 3 V/ms, which affects its response time to changes in input signals.
This model features 2 channels, making it a dual operational amplifier for various applications.
