| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C3V6-QYL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 7.5μA |
| Nominal Zener Voltage Vz | 3.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 600Ω |
| Typical Voltage Temperature Coefficient | -3.5mV/K |
Nexperia BZX8850S-C3V6-QYL is a 3.6 V Zener diode in a single diode configuration, designed for surface mount applications with compact 2-pin DFN1006BD-2 package. It operates as a voltage regulator with a maximum power dissipation of 365 mW, making it suitable for low current and portable battery-powered circuits.
This diode features a nominal Zener voltage of 3.6 V with a tolerance of ±5%, providing stable voltage regulation under varying operating conditions. Its low test current of 50 µA allows efficient operation in low bias environments.
The component meets automotive industry standards with AEC-Q101 qualification, ensuring reliability in demanding automotive electronic applications. It supports an operating temperature range from -55°C to 150°C, making it versatile for various industrial, automotive, laboratory, and electronic manufacturing uses.
The diode’s maximum Zener impedance of 600 Ω and a voltage temperature coefficient of -3.5 mV/K ensure consistent voltage output despite temperature fluctuations. It has a maximum reverse leakage current of 7.5 µA which minimizes power loss.
The ultra-small package size with length 1 mm and height 0.47 mm optimizes PCB layout space without compromising performance. Nexperia’s BZX8850S series is well-regarded for robust voltage regulation in discrete semiconductor applications.
Nominal voltage: 3.6 V with ±5% tolerance. Power dissipation: 365 mW. Package: DFN1006BD-2, 2-pin surface mount. Test current: 50 µA for low bias applications. Operating temperature range: -55°C to 150°C. Automotive standard AEC-Q101 certified.
Typical voltage temperature coefficient: -3.5 mV/K. Maximum Zener impedance 600 Ω. Maximum reverse leakage current 7.5 µA. Compact length 1 mm and height 0.47 mm.
This Zener Diode is suitable for a wide range of applications including industrial electronics, automotive systems, laboratory instrumentation, and general electronic component assemblies. Its robust design and small form factor aid in efficient power management and voltage regulation.
