Eaton xPole Miniature Circuit Breaker, 3-Pole, 25A Current Rating, Type C Tripping, 400V AC, 48V DC, 10 kA 236428 PXL-C25/3

The Eaton 236428 PXL-C25/3 xPole Miniature Circuit Breaker is designed for industrial and commercial electrical applications requiring reliable protection and high selectivity. This 3-pole breaker supports a current rating of 25 amperes and features a Type C tripping characteristic allowing it to handle moderate inrush currents typical in motor and lighting circuits.

Rated for both AC (400 volts) and DC (48 volts) applications, it delivers a robust breaking capacity of 10 kiloamperes to protect circuits against overload and short circuit faults effectively. The device is engineered for easy installation on DIN rails, complying with IEC/EN 60715 top-hat rail standards. Its double terminal design with lift and jaw contacts ensures secure connections and compatibility with bus bars, enhancing versatility in switchgear assemblies.

Safety is paramount with this breaker featuring finger-proof and back-of-hand-proof construction to minimize electrical hazards during operation and maintenance. The toggle switch enables a straightforward reset after tripping, and the instantaneous electromagnetic tripping mechanism facilitates rapid interruption of fault currents.

Its compact form factor with dimensions of 80mm width, 52.5mm height, and 60mm depth allows integration in confined electrical panels while maintaining an IP20 protection rating to guard against solid objects.

Compliant with widely recognized EN 60898 and IEC standards, this Eaton Miniature Circuit Breaker is a trusted choice for electrical installations requiring precise and dependable circuit protection in industrial, manufacturing, HVAC, and commercial power distribution environments.

Suitable for DIN rail mounting with high selectivity as a pre-fuse with low passband energy. Equipped with double terminal connection, lift/jaw top and bottom for bus bar compatibility. Supports free selection of rail arrangement at both top and bottom.

Designed with finger-proof and back-of-hand-proof safety features. Offers quick-fit action with three locking positions for top-hat rail IEC/EN 60715 compliance. Features toggle switch reset actuator with instantaneous electromagnetic tripping mechanism.

Compact dimensions: 80mm width, 52.5mm height, 60mm depth with IP20 rating. Compliant with EN 60898 and IEC standards ensuring reliable operation.

This Eaton xPole model provides reliable overload and short circuit protection tailored for industrial, laboratory, construction, HVAC, manufacturing, and commercial electrical systems. Browse Eaton products and circuit breaker ranges at EnvMart for comprehensive electrical protection solutions.
