Honeywell Technologies Piezoresistive Pressure Sensor Board SMT 8 Pin 3.3-5V 100kPa ±0.25% Accuracy HSCMAND001BAAA5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 100 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | HSCMAND001BAAA5 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Width | 13.3mm |
| Mount Type | Board |
| Series | HSC |
| Maximum Operating Temperature | +85°C |
| Port Type | Single Axial Barbed |
| Package Type | SMT |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | ISO 9001 |
| Pin Count | 8 |
| Automotive Standard | ISO 9001 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 0bar |
| Maximum Overload Pressure | 200kPa |
Key Features
- This sensor measures absolute, gauge, or differential pressure in non-corrosive, non-ionic gases with high precision.
- Equipped with 8-pin SMT packaging for compact PCB integration and electrical connection.
- Provides ratiometric analogue output or 14-bit digital output compatible with I2C or SPI interfaces.
- Supports enhanced robustness with 200kPa maximum overload pressure tolerance.
- Operates reliably from -20°C to +85°C with temperature compensation for consistent accuracy.
- Low power consumption under 10mW suitable for battery-powered applications.
- Conforms to ISO 9001 quality standards ensuring reliable industrial performance.
- Ideal for medical ventilators, HVAC transmitters, gas flow instrumentation, and industrial automation.
Product Description
Honeywell Technologies HSCMAND001BAAA5 is a piezoresistive pressure sensor board designed for SMT mounting with an 8-pin package. It operates between 3.3V and 5V power supply voltages and can accurately measure up to 100kPa of pressure with ±0.25% FSS accuracy.
This sensor supports measurement of absolute, gauge, or differential pressure in non-corrosive, non-ionic gases and certain compatible liquids via a single axial barbed port. It offers both ratiometric analogue output and a 14-bit digital output via I2C or SPI for seamless integration with microcontrollers.
With a maximum overload pressure tolerance of 200kPa, the device is robust against pressure spikes, while typical power consumption below 10mW makes it suitable for battery-powered and portable applications. The sensor is calibrated to operate effectively across a temperature range from -20°C to +85°C, maintaining precision across conditions.
The HSCMAND001BAAA5 complies with ISO 9001 standards, endorsing its manufacturing quality and reliability. Its compact dimensions (13.75mm height, 13.3mm width, 10mm length) and board mount form factor facilitate easy PCB integration in various industrial and commercial equipment.
Applications include medical ventilator and respiratory monitoring systems, HVAC air quality transmitters, differential flow measurement, gas flow instrumentation, laboratory calibrators, and pneumatic control in automation systems. The sensor’s fast output updates (approx. 1kHz analogue, 2kHz digital) support responsive control loops in critical environments.
This sensor provides precise and fast pressure measurement for a broad range of industrial and laboratory applications. Compact SMT 8 pin design enables easy PCB integration and low footprint installation. Low power and wide operating voltage support energy-efficient and versatile usage scenarios.
Temperature compensation ensures stable operation over an extended temperature range. ISO 9001 certification guarantees consistent product quality. Designed for non-corrosive gases and selected liquid media, broadening application diversity.
Robust overload pressure tolerance improves system reliability against pressure surges. Calibrated analogue and digital outputs provide flexible interface compatibility.
The Honeywell piezoresistive pressure sensor HSCMAND001BAAA5 represents a high-quality component for precision pressure sensing needs across industrial, environmental, medical, and HVAC fields. Browse similar Honeywell sensor ICs and pressure sensors at EnvMart for comprehensive selection and solutions.
Explore more products in our Pressure Sensor IC category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this sensor is 100 kPa.
This model has an accuracy rating of ±0.25%.
It offers both ratiometric analogue output and a 14-bit digital output compatible with I2C or SPI interfaces.
The sensor operates reliably within a temperature range of -20°C to +85°C.
The dimensions of this model are 13.75mm in height, 13.3mm in width, and 10mm in length.
This unit is designed for board mounting with an SMT package.
It operates with a power supply voltage ranging from 3.3V to 5V.
The maximum overload pressure tolerance is 200 kPa.
It is suitable for applications such as medical ventilators, HVAC transmitters, gas flow instrumentation, and industrial automation.
This sensor features an 8-pin configuration.
Yes, it conforms to ISO 9001 quality standards.
It measures absolute, gauge, or differential pressure in non-corrosive, non-ionic gases and certain compatible liquids.
