Vishay 120 V 35 A Surface Mount Schottky Rectifier Diode TO-252 Package V35PW12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 13in |
| Brand | Vishay |
| Height | 1.3mm |
| Length | 6.1mm |
| Model | V35PW12HM3/I |
| Width | 6.1mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS, UL 94 V-0, AEC-Q101 |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 35A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 60mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 260A |
| Maximum Forward Voltage Vf | 1.05V |
Key Features
- Features trench MOS technology for low forward voltage drop.
- Supports maximum forward surge current of 260 A for surge protection.
- Operates over temperature range -40°C to 150°C ensuring durability.
- Complies with automotive standard AEC-Q101 for quality and reliability.
- Compact dimensions of 6.1 mm length, 6.1 mm width, and 1.3 mm height facilitate compact PCB layouts.
- Ideal for DC/DC converter, freewheeling diode, and polarity protection applications.
- Offers low power losses and high efficiency operation.
- RoHS compliant and UL 94 V-0 rated for safety and environmental compliance.
Product Description
Vishay V35PW12HM3/I is a high-current density Schottky rectifier diode designed for surface-mount applications. It delivers a maximum continuous forward current of 35 A and a peak reverse repetitive voltage of 120 V.
The diode features advanced trench MOS Schottky technology, providing a low forward voltage drop of 1.05 V and thus enabling high efficiency with reduced power dissipation. It has a small form factor with a TO-252 package measuring 6.1 mm by 6.1 mm with a height of 1.3 mm, making it suitable for high-density PCB assemblies.
This component operates reliably within a temperature range of -40°C to 150°C and withstands peak non-repetitive forward surge currents up to 260 A. It has a standard 3-pin configuration typical for rectifier and Schottky diodes, facilitating easy integration.
The diode conforms to automotive industry standard AEC-Q101, making it suitable for automotive, industrial, and consumer electronics applications requiring robust performance and high reliability. It is also RoHS and UL 94 V-0 compliant, ensuring environmental and safety standards are met.
Applications include low voltage high frequency DC/DC converters, freewheeling diodes, polarity protection circuits, and other power conversion or protection roles in semiconductor devices.
Trench MOS Schottky technology for low forward voltage drop. High efficiency operation resulting in low power losses. Compliant with automotive standard AEC-Q101 and industrial safety norms. Compact TO-252 surface mount package.
Wide operating temperature range from -40°C to 150°C. Reliable peak surge protection with 260 A forward surge current capability. RoHS compliant for environmental safety. Explore the Vishay range of semiconductors and Schottky diodes at EnvMart for your power electronics needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this model is 35 A.
The dimensions of the TO-252 package are 6.1 mm in length, 6.1 mm in width, and 1.3 mm in height.
It operates reliably within a temperature range of -40°C to 150°C.
The diode can withstand peak non-repetitive forward surge currents up to 260 A.
It complies with the automotive standard AEC-Q101 for quality and reliability.
This model supports surface mounting.
The maximum forward voltage drop is 1.05 V.
It is RoHS compliant and UL 94 V-0 rated for safety and environmental compliance.
This diode has a standard 3-pin configuration typical for rectifier and Schottky diodes.
It features trench MOS technology for a low forward voltage drop, enabling high efficiency with reduced power dissipation.
