Europa Miniature Circuit Breaker, 2-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC2P

Free Delivery in India | Lowest Global Shipping Charges

Europa Miniature Circuit Breaker, 2-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC2P

Name: Europa Miniature Circuit Breaker, 2-Pole, 32A, Type C, 400V AC, 10 kA Breaking Capacity EUC2P
Brand: Europa
SKU: 287803
Price: 22.29 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Europa Condition New

Specifications

Country of Origin	China
Range	EUC2P
Brand	Europa
Height	36mm
Model	EUC2P
Depth	87mm
IP Rating	IP20
Width	78mm
Mount Type	DIN Rail
Current Rating	32A
Terminal Capacity	1mm2 to 25mm2
Series	EUC2P
Terminal type	Tunnel
Breaking Capacity	10kA
Number of Poles	2
Standards/Approvals	EN 60898, IEC 60898, SEMKO, CE
Rated AC Voltage	400V ac
Tripping Characteristics	Type C
Reset Actuator Type	Toggle Switch

Key Features

Designed for DIN rail mounting with 2 poles and a current rating of 32A.
Features Type C tripping characteristics suitable for general applications.
Rated for 400V AC with a breaking capacity of 10 kA for enhanced safety.
Compact dimensions of 78mm width, 87mm depth, and 36mm height with IP20 protection rating.
Equipped with a toggle switch reset actuator for easy operation and tunnel terminal type.
Terminal capacity supports conductor sizes from 1mm² to 25mm² for flexible wiring.
Conforms to standards IEC 60898, EN 60898 and carries CE and SEMKO approvals.
Operates safely within an ambient temperature range of -5°C to 40°C.

Product Description

Europa EUC2P Miniature Circuit Breaker model EUC2P is a 2-pole device designed for reliable electrical protection in residential and commercial installations. It supports a current rating of 32A with Type C tripping characteristics, making it ideal for general circuit protection applications. The breaker is rated for a voltage of 400V AC and provides a high breaking capacity of 10 kA, ensuring safety against short circuits and overloads.

This compact circuit breaker is designed for DIN rail mounting and features a toggle switch reset actuator for straightforward circuit resetting post-trip. The terminal type is tunnel style, accommodating conductor sizes ranging from 1mm² to 25mm², allowing versatile wiring options.

With dimensions of 78mm in width, 87mm in depth, and 36mm in height, it fits well within standard consumer units and adheres to IP20 ingress protection rating, safeguarding internal components from solid foreign objects. It complies with international standards IEC 60898 and EN 60898, having CE and SEMKO approvals that guarantee quality and safety.

The operating temperature range from -5°C to 40°C allows reliable function in varied environments. The breaker is made in China and integrates seamlessly into electrical automation, industrial control panels, and residential electrical distribution setups.

Designed for 2-pole circuit protection with 32A current rating. Type C tripping characteristic suitable for general electrical loads. Provides 10 kA breaking capacity and 400V AC voltage rating. Mounts on 35mm DIN rail for ease of installation.

Supports conductor sizes from 1mm² to 25mm² with tunnel terminals. Meets IEC 60898, EN 60898 standards with CE and SEMKO approvals. Toggle switch actuator allows easy manual reset after tripping. Compact size and IP20 rating ensure compatibility and protection.

This Miniature Circuit Breaker is essential for protecting electrical circuits from damage caused by overload or short circuits in industrial, commercial, and residential applications. Browse the Electronics & Electricals category on EnvMart for a wide range of high-quality circuit breakers and electrical protection devices from trusted brands like Europa.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 32A, making it suitable for general circuit protection applications.

The breaking capacity of this circuit breaker is 10 kA, providing enhanced safety against short circuits and overloads.

It is rated for 400V AC, making it suitable for various electrical installations.

This unit features Type C tripping characteristics, which are suitable for general applications.

The dimensions of this circuit breaker are 78mm in width, 87mm in depth, and 36mm in height.

It supports conductor sizes from 1mm² to 25mm², allowing for flexible wiring options.

This model is designed for DIN rail mounting, facilitating easy installation in standard consumer units.

It has an IP20 protection rating, safeguarding internal components from solid foreign objects.

It conforms to IEC 60898 and EN 60898 standards and carries CE and SEMKO approvals.

The operating temperature range is from -5°C to 40°C, ensuring reliable function in varied environments.

It is equipped with a toggle switch reset actuator, allowing for easy manual resetting after a trip.

This miniature circuit breaker is essential for protecting electrical circuits from damage caused by overload or short circuits in residential and commercial installations.
