Europa Miniature Circuit Breaker 1-Pole 40A Type B 400V AC 10 kA Breaking Capacity EUC1P
Specifications
| Country of Origin | China |
|---|---|
| Range | EUC1P |
| Brand | Europa |
| Height | 18mm |
| Model | EUC1P |
| Depth | 87mm |
| IP Rating | IP20 |
| Width | 78mm |
| Mount Type | DIN Rail |
| Current Rating | 40A |
| Terminal Capacity | 1mm2 to 25mm2 |
| Series | EUC1P |
| Terminal type | Tunnel |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | CE, EN 60898, IEC 60898, SEMKO |
| Rated AC Voltage | 400V ac |
| Tripping Characteristics | Type B |
| Reset Actuator Type | Toggle Switch |
Key Features
- Compact design suitable for DIN Rail mounting.
- Rated current capacity of 40 amperes for effective circuit protection.
- Tripping characteristic Type B ensures protection against overloads and short circuits.
- IP20 rated for protection against solid objects larger than 12 mm.
- Constructed with toggle switch actuator for easy manual operation.
- Terminal capacity supports wiring from 1 mm² to 25 mm².
- Compliance with IEC 60898, EN 60898 standards for safety and reliability.
Product Description
Europa EUC1P Miniature Circuit Breaker, model EUC1P, is a 1-pole MCB rated at 40A with type B tripping characteristics, designed to operate at 400V AC with a breaking capacity of 10 kA. It is engineered to fit into consumer units and distribution boards, providing reliable protection against overloads and short circuits in electrical installations.
This MCB features a toggle switch reset actuator for convenient manual switching, and its terminal type is tunnel with wiring capacity ranging from 1 mm² to 25 mm², ensuring adaptability to various standard electrical wires. The breaker mounts securely on a 35 mm DIN rail, streamlining installation in typical panel configurations.
With an IP20 rating, the breaker offers protection against solid objects larger than 12 mm while maintaining safety in typical indoor electrical environments. The device complies with international IEC 60898 and European EN 60898 standards, backed by CE and SEMKO approvals, ensuring high quality and safety for domestic, commercial, and light industrial applications.
The compact dimensions (18 mm height, 78 mm width, 87 mm depth) contribute to space-saving arrangements in electrical panels. Suitable for operating temperature ranges between -5° to 40°C, the breaker maintains performance under typical ambient conditions.
Compact DIN rail mount design for easy integration into electrical panels. 40A current rating delivering effective circuit protection. Type B tripping characteristic suitable for residential and light commercial use. Toggle switch actuator for safe and convenient reset operations.
Terminal capacity supports diverse wiring gauges from 1mm² to 25mm². Certified to IEC 60898 and EN 60898 safety standards with CE and SEMKO marks. Dimensions ideal for compact panel layouts: 18 mm height, 78 mm width, 87 mm depth.
IP20 protection rating against solid foreign objects.
This Europa EUC1P Miniature Circuit Breaker is ideal for use in electrical automation, residential, commercial, and light industrial electrical distribution systems. It ensures safe and reliable disconnect and over-current protection for circuits by instantly breaking the flow of electricity during faults.
Explore more electrical protection devices and components at EnvMart for reliable circuit safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 40A, providing effective circuit protection for various applications.
The breaking capacity of this circuit breaker is 10 kA, allowing it to handle significant fault currents safely.
The dimensions of this unit are 18 mm in height, 78 mm in width, and 87 mm in depth, making it suitable for compact installations.
It is designed for DIN rail mounting, facilitating easy installation in electrical panels.
This model has an IP20 rating, which protects against solid objects larger than 12 mm, suitable for indoor environments.
The circuit breaker features Type B tripping characteristics, making it suitable for residential and light commercial applications.
The terminal capacity supports wiring from 1 mm² to 25 mm², accommodating a range of standard electrical wires.
It complies with IEC 60898 and EN 60898 standards, and is marked with CE and SEMKO approvals for safety and reliability.
This model uses a toggle switch actuator for manual reset operations, allowing for convenient control.
The rated AC voltage for this circuit breaker is 400V, making it suitable for standard electrical systems.
It operates effectively within a temperature range of -5° to 40°C, suitable for typical ambient conditions.
This miniature circuit breaker is ideal for use in residential, commercial, and light industrial electrical distribution systems.
