Honeywell Technologies FSS-SMT Series Low Profile Load Cell, Tension & Compression, 0 N to 0.51 kg, Plastic FSS005WNGB
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 16.8mm |
| Model | FSS005WNGB |
| Depth | 3.38mm |
| Sensor Type | Low Profile |
| Width | 5.59mm |
| Mount Type | Surface |
| Housing Material | Plastic |
| Series | FSS-SMT |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Terminal type | Pin |
| Maximum dc Voltage | 10V dc |
| Force Measured | Tension, Compression |
| Maximum Force/Load Measurement | 0.51kg |
| Minimum Force/Load Measurement | 0N |
Key Features
- The sensor uses piezoresistive micromachined silicon for precise force sensing.
- Low deflection minimizes measurement errors while maintaining accuracy.
- Compact size fits small PCB spaces with dimensions 16.8mm x 5.59mm x 3.38mm.
- Plastic housing ensures durability with surface mount pin terminals for easy installation.
- Operates on low voltage supply of 10 V DC to support battery-powered systems.
- Suitable for applications requiring tension and compression force measurement.
- Operating temperature range from -40°C to 85°C accommodates various environments.
- Manufactured in China according to product origin details.
Product Description
Honeywell Technologies FSS005WNGB is a low profile load cell sensor optimized for accurate measurement of tension and compression forces up to 0.51 kg. This sensor incorporates piezoresistive micromachined silicon technology to deliver reliable force sensing performance in industrial and laboratory settings.
Its compact dimensions of length 16.8 mm, width 5.59 mm, and depth 3.38 mm make it suitable for integration on printed circuit boards where space is limited. The plastic housing protects the sensor while its surface mount pin terminal design enables straightforward electrical connection.
Operating with a maximum DC voltage of 10 V, the load cell supports battery-operated and low voltage systems. It performs consistently across a wide temperature range from -40°C to 85°C, suitable for diverse industrial, laboratory, and automation applications where force measurement is critical.
This sensor's low deflection characteristic reduces measurement inaccuracies and improves output stability. It is RoHS compliant, reflecting adherence to environmental standards. Although no specific approvals or certifications are listed, the device is manufactured in China following quality practices.
Typical use cases include automation systems, force monitoring in manufacturing, sensor applications in electronics, and other industrial environments requiring precise load and force feedback. The robust construction and surface mount configuration emphasize ease of installation and reliability.
The sensor uses piezoresistive micromachined silicon technology for precision force measurements. Low deflection reduces errors and improves measurement accuracy. Compact size enables integration into tight PCB spaces. Plastic housing and surface mount pin terminals for durability and ease of installation.
Supports low voltage operation with a max 10 V DC supply. Wide operating temperature range: -40°C to 85°C. RoHS compliant for environmental safety. Suitable for industrial, lab, and automation force measurement applications.
Manufactured in China. Explore the Electronics & Electricals category for more sensors and Load Cells from leading manufacturers like Honeywell at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load measurement for this model is 0.51 kg, allowing it to measure both tension and compression forces within this range.
This load cell has compact dimensions of 16.8 mm in length, 5.59 mm in width, and 3.38 mm in depth, making it suitable for tight PCB spaces.
The operating temperature range for this unit is from -40°C to 85°C, accommodating a variety of environmental conditions.
It features a plastic housing, which provides protection and durability for the sensor.
The load cell operates on a maximum DC voltage supply of 10 V, making it suitable for battery-powered systems.
This model uses a surface mount configuration, which allows for straightforward installation on printed circuit boards.
It uses piezoresistive micromachined silicon technology, which enhances the accuracy of force measurements.
Yes, the sensor is RoHS compliant, indicating adherence to environmental safety standards.
It is designed to measure both tension and compression forces, making it versatile for various applications.
The FSS005WNGB features pin terminals, which facilitate easy electrical connections during installation.
This load cell is manufactured in China, following quality practices.
It is suitable for applications in industrial, laboratory, and automation settings that require precise force measurement.
