Honeywell Technologies FSS Series Miniature Load Cell, Tension and Compression Measurement, 0.51 kg, Plastic FSS005WNSB
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 19.05mm |
| Model | FSS005WNSB |
| Depth | 3.38mm |
| Sensor Type | Miniature |
| Width | 5.59mm |
| Mount Type | Surface |
| Housing Material | Plastic |
| Series | FSS |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Terminal type | Pin |
| Maximum dc Voltage | 10V dc |
| Force Measured | Tension, Compression |
| Maximum Force/Load Measurement | 0.51kg |
| Minimum Force/Load Measurement | 0N |
Key Features
- The sensor features a low profile design ideal for limited PCB space applications.
- Plastic housing ensures lightweight and durability with resistance to environmental factors.
- Pin terminal type supports reliable electrical connection.
- Surface mount installation simplifies integration into various systems.
- Operates efficiently under a maximum DC voltage of 10 V dc, suitable for battery-powered devices.
- Supports a broad operating temperature range from -40°C to 85°C.
- Micro machined piezoresistive silicon sensing element provides high accuracy and low deflection.
- Designed to minimize measurement errors and resist mounting stresses.
Product Description
The Honeywell Technologies FSS Series Miniature Load Cell model FSS005WNSB is a precision force sensor designed to accurately measure tension and compression forces up to 0.51 kg. Featuring a micro machined piezoresistive silicon sensing element, this sensor offers excellent reliability and low measurement deflection, reducing errors in force sensing applications.
Its compact plastic housing and miniature size (19.05 mm length, 5.59 mm width, and 3.38 mm depth) make it ideal for space-constrained industrial and commercial applications, including automation, robotics, instrumentation, and battery-powered devices.
The load cell supports a maximum DC voltage of 10 V dc and operates effectively within a temperature range of -40°C to 85°C. The pin terminal and surface mount design allow for easy installation and integration into existing systems.
This sensor's low sensitivity to mounting stresses enhances measurement stability, ensuring consistent performance in various settings. It is RoHS-compliant, making it suitable for environmentally conscious applications.
The sensor’s low profile design minimizes PCB space while maintaining accuracy. Plastic housing enhances durability and environmental resistance. Pin terminals provide secure electrical interface. Surface mount style facilitates compact and versatile installation.
Supports 10 V dc max voltage enabling battery-powered system compatibility. Wide operating temperature range from -40°C to 85°C ensures functionality in harsh environments. Micro machined piezoresistive element offers precise force detection.
Low deflection diminishes measurement errors and enhances reliability. RoHS compliance denotes adherence to environmental safety standards. Physical dimensions fit compact and embedded applications. This load cell is extensively suited for industrial automation, laboratory instrumentation, manufacturing processes, robotics, quality control, and sensor research applications.
Select Honeywell FSS series Load Cells for accurate, compact, and reliable force measurement solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Honeywell FSS Series Miniature Load Cell can measure a maximum force of 0.51 kg.
This load cell operates effectively within a temperature range from -40°C to 85°C.
It is designed to measure both tension and compression forces.
The load cell features a plastic housing, which enhances its durability and resistance to environmental factors.
The dimensions of this model are 19.05 mm in length, 5.59 mm in width, and 3.38 mm in depth.
It supports a maximum DC voltage of 10 V dc, making it suitable for battery-powered devices.
This model features a surface mount design, which simplifies integration into various systems.
It utilizes pin terminals for a reliable electrical connection.
This load cell is designed to minimize sensitivity to mounting stresses, enhancing measurement stability.
Yes, it is RoHS-compliant, indicating adherence to environmental safety standards.
It is extensively suited for applications in industrial automation, laboratory instrumentation, manufacturing processes, robotics, and quality control.
It features a micro machined piezoresistive silicon sensing element, which provides high accuracy and low deflection.
