Eaton xEffect Miniature Circuit Breaker 1-Pole 6A Type B 240V AC 48V DC 10kA Breaking Capacity 278642 FAZ-B6/1N
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 278642 FAZ-B6/1N |
| Depth | 80mm |
| IP Rating | IP20 |
| Width | 66mm |
| Mount Type | DIN Rail |
| Current Rating | 6A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type B |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
| MCB Module widths | 1P 17.5mm, 2P 35mm and 3P 52.5mm |
Key Features
- Offers thermal-magnetic overcurrent protection to safeguard electrical circuits.
- Rated for 240V AC and 48V DC operation ensuring versatile use.
- Breaking capacity of 10 kA enables rapid interruption of short circuits.
- Mounts easily on DIN rails for efficient installation in control panels.
- Features toggle switch actuator with clear contact position indication.
- Equipped with screw terminals for secure wiring connections.
- Compact width of 17.5 mm per pole optimizes panel space usage.
- Type B tripping characteristic suitable for residential and commercial applications.
Product Description
Eaton 278642 FAZ-B6/1N Miniature Circuit Breaker from the xEffect range is designed for fast and reliable overcurrent protection in low voltage electrical installations. This 1-pole MCB has a current rating of 6 amps, Type B tripping characteristics, and supports both 240V AC and 48V DC supply voltages.
Equipped with a thermal-magnetic release mechanism, it provides rapid interruption of electrical faults, protecting circuits from overload and short circuits. The device features a robust toggle switch for easy manual operation and a trip-free mechanism that prevents the breaker from being held ON during a fault.
The compact design with only 17.5 mm module width per pole allows efficient use of space in distribution boards and control panels. It is compatible with DIN rail mounting systems and uses screw terminal connections for secure wiring.
The FAZ series MCBs from Eaton include a range of accessories such as interlocks, busbars, auxiliaries, and tripping modules, making it a versatile solution for various industrial, commercial, and residential electrical installations.
This breaker conforms to industry standards IEC 898 and IEC/EN60947-2, ensuring compliance with safety and performance requirements. Its finger-proof design and IP20 rating offer additional user protection.
Thermal-magnetic overcurrent protection ensures circuit safety. Supports 240V AC and 48V DC to cover multiple applications. 10 kA breaking capacity provides reliable fault interruption. Compact 17.5 mm width per pole saves panel space.
DIN rail mounting facilitates quick installation and maintenance. Toggle switch enables clear contact position indication. Screw terminals guarantee secure electrical connections. Complies with IEC and EN standards for electrical safety.
This Eaton Miniature Circuit Breaker is ideal for electrical distribution boards, control circuits, and protection of residential and commercial installations. Discover more Eaton electrical protection devices and components in the Circuit Breakers category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6A.
It supports both 240V AC and 48V DC supply voltages.
The breaking capacity is 10 kA, allowing for rapid interruption of short circuits.
It features a thermal-magnetic tripping mechanism.
This unit is designed for DIN rail mounting, facilitating efficient installation.
The width is 17.5 mm per pole, optimizing space in distribution boards.
The dimensions are 80 mm in depth and 66 mm in width.
It is equipped with screw terminals for secure wiring connections.
The IP rating is IP20, providing a level of protection against solid objects.
It is suitable for residential and commercial electrical installations.
The tripping characteristic is Type B, making it suitable for various applications.
It complies with industry standards IEC 898 and IEC/EN60947-2 for safety and performance.
