Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 20A, Type D, 240V AC, 48V DC, 10kA Breaking Capacity 278585 FAZ-D20/1

Eaton 278585 FAZ-D20/1 miniature circuit breaker is part of the xEffect FAZ series, providing robust 1-pole overcurrent protection with a 20A current rating. This device ensures fast and safe interruption of fault currents with a 10 kA breaking capacity, protecting electrical circuits in industrial and commercial applications.

Designed to operate at a rated AC voltage of 240V and rated DC voltage of 48V, it offers dual voltage compatibility suitable for multiple electrical environments. The thermal-magnetic tripping mechanism combines thermal overload and electromagnetic short-circuit protection, preventing damage due to electrical faults.

With a compact module width of 17.5 mm and DIN rail mounting, installation in distribution boards and control panels is efficient and space-saving. The breaker’s toggling switch and instantaneous break time add to operational safety and ease of use. Its IP20 rating certifies finger protection against accidental contact.

Additionally, the trip-free mechanism ensures the breaker cannot be held in the ON position, enforcing automatic tripping during fault conditions for enhanced safety. The FAZ series supports a range of modular accessories, including interlocks and auxiliary contacts, allowing customization as per industrial and commercial requirements.

This miniature circuit breaker is ideally suited for use in industrial, commercial, and electrical distribution systems, safeguarding equipment against overloads and short circuits.

This Miniature Circuit Breaker is designed for quick and reliable short-circuit interruption with a 10 kA breaking capacity. It operates at rated AC voltage of 240V and DC voltage of 48V for versatile power protection. The thermal-magnetic tripping mechanism ensures rapid response to overload and short circuits.

DIN rail mounting and screw terminal type facilitate easy installation and secure connectivity. Compact design with a width of 17.5 mm for the single-pole module saves panel space. Features a toggle switch actuator and instantaneous break time for user-friendly operation.

IP20 rated for finger protection and equipped with trip-free mechanism for enhanced safety. Compatible with Eaton’s xEffect FAZ series accessories and modules for extended functionality. Explore a broad range of circuit breakers and electrical protection devices at EnvMart to enhance your industrial and commercial electrical systems.
