Eaton xEffect Miniature Circuit Breaker, 3-Pole, 63A, Type D, 415V AC, 96V DC, 10 kA Breaking Capacity 115375 FAZ-D63/3

Eaton 115375 FAZ-D63/3 Miniature Circuit Breaker is a high-quality, three-pole electrical protection device designed for commercial, industrial, and advanced switchgear applications. It features a current rating of 63 amperes and Type D tripping characteristics, ideal for circuits with high inrush currents such as motors and transformers.

This FAZ series MCB operates effectively at an AC voltage of 415 volts and DC voltage up to 96 volts, making it versatile for various electrical systems. The breaker integrates thermal-magnetic tripping mechanisms that provide reliable protection by responding quickly to overloads and short circuits, enhancing operational safety and longevity of connected equipment.

The unit features a robust design with compact dimensions measuring 54mm in width and 80mm in depth, optimized for installation on DIN rails with secure screw terminals. Its IP20 rating ensures appropriate protection against solid foreign objects in typical indoor environments.

The 10 kA breaking capacity supports high fault current interruption, minimizing the risk of damage or fire hazards. Instantaneous break time ensures immediate fault response, critical in industrial and commercial distribution networks.

Conforming to internationally recognized safety standards such as BS EN 60898, EN 50 022/DIN 46277-3, and IEC 898, the device ensures compliance and reliability. Additionally, it operates within a temperature range of -40°C to 70°C, suitable for diverse environmental conditions.

DIN rail mounting with screw terminals facilitates easy and secure installation. 63A rating with Type D tripping suited for high inrush current circuits. High 10 kA breaking capacity for robust fault current protection. Rated for 415V AC and 96V DC operational voltages.

Compact design dimensions (54mm width x 80mm depth) save space. Instantaneous break time enhances safety and fault interruption speed. IP20 rated for protection against solid objects in indoor use. Compliant with BS EN 60898, IEC 898, and related standards.

Operates reliably from -40°C to 70°C temperature range.

This Eaton Miniature Circuit Breaker is ideal for industrial automation, commercial electrical distribution, and manufacturing facilities requiring high-quality circuit protection solutions. It is suitable for use in switchgear panels for reliable electrical fault management.
