HOBUT Analogue Panel Ammeter 100 A AC/DC, CT Operated, DIN Moving Iron, Accuracy Class 1.5, UK D72SD5A/0-600A

HOBUT D72SD5A/0-600A Analogue Panel Ammeter is a high-precision CT operated DIN moving iron ammeter designed for measuring AC and DC current up to 100 A. Manufactured in the United Kingdom to BS 89 and IEC 51 standards, this instrument delivers reliable and accurate current measurement with an accuracy class of 1.5, making it suitable for industrial, manufacturing, and process control applications.

The instrument features a 90° scale arc for easy readability and a flame retardant case rated to UL94V0, ensuring safety and durability under demanding conditions. It operates efficiently within a temperature range from -25°C to +40°C, allowing it to be used in various operational environments.

Installation is simplified with panel cut out requirements of 68 x 68 mm and 92 x 92 mm and mounting brackets supplied with the unit. The ammeter is compatible with current transformers having 5A secondaries, using 5A full scale deflection movements. For added protection, terminal covers are available separately as accessories.

This panel ammeter provides an overload capacity of 10 times rated full scale deflection for 5 seconds, ensuring resilience to current surges. Its compliance with multiple standards including IEC 51, ES50-2, DIN 43700, UL94V0, and BS 89 certifies it as a quality and safety-conscious choice.

Measures both AC and DC currents up to 100 A with high accuracy. Flame retardant casing for enhanced safety. Wide operating temperature range suitable for industrial environments. Standard panel cut outs enabling easy integration into control panels.

Overload rating ensures protection in power surges. Manufactured under strict standards ensuring quality and reliability. Compatible with standard current transformers for versatile use. Supplied with mounting brackets for secure installation.

Terminal covers available to enhance user safety.

This ammeter is ideal for industrial automation, electrical panels, process control units, and other commercial and manufacturing facility electrical measurement needs. Explore more products in the Analogue Panel Ammeter category at EnvMart for comprehensive electrical measurement solutions.
