HOBUT Analogue Panel Ammeter 100 A AC 48 mm x 48 mm Class 1.5 Moving Iron D48SD

Free Delivery in India | Lowest Global Shipping Charges

HOBUT Analogue Panel Ammeter 100 A AC 48 mm x 48 mm Class 1.5 Moving Iron D48SD

Name: HOBUT Analogue Panel Ammeter 100 A AC 48 mm x 48 mm Class 1.5 Moving Iron D48SD
Brand: HOBUT
SKU: 154628
Price: 33.16 USD
Availability: InStock



Category Analogue Panel Ammeter Brand HOBUT Condition New

Specifications

Country of Origin	United Kingdom
Brand	HOBUT
Model	D48SD
Depth	43mm
Series	D48SD
Maximum Operating Temperature	40°C
Current Type	AC
Meter Accuracy	Class 1.5
Minimum Operating Temperature	-25°C
Standards/Approvals	IP54, DIN 43700, IEC 51, IP52, DIN 43802, BS 89, UL94V0, UL94V1
Cutout Height	48mm
Cutout Width	48mm
ANSI/ESD S20.20	2014
BS EN 61340-5-1	2007
Moving Element	Moving Iron
Maximum Ampere Value	100 A
DIN 48 METER 0-25ABrand	NEUTRAL
RS PRO Analogue Panel Ammeter 25 A AC, 45 mm x 45 mm, 1 % Moving IronBrand	RS PRO

Key Features

The ammeter operates on alternating current with a maximum rating of 100 A.
It features a moving iron indication element with class 1.5 accuracy for reliable readings.
The compact panel meter has cut-out dimensions of 48 mm height and width and a depth of 43 mm.
Designed to operate in temperature ranges from -25°C to 40°C, suitable for various industrial environments.
Includes mounting brackets for easy installation in control panels.
The scale is replaceable and includes a front zero-point regulator for calibration.
Constructed to standards including IP54 protection, DIN 43700, IEC 51, DIN 43802, BS 89, and flame retardant UL94V0 and UL94V1.
Manufactured in the United Kingdom ensuring quality and durability.

Product Description

HOBUT D48SD Analogue Panel Ammeter 100 A AC is an industrial-grade panel meter designed for accurate measurement of alternating current with a moving iron mechanism. It features a compact design with a 48 mm by 48 mm cutout size and a depth of 43 mm, making it suitable for integration into electrical control panels and automation gear.

The meter offers class 1.5 accuracy, ensuring dependable readings within its rated capacity. Operating reliably between -25°C and 40°C, it is engineered for challenging industrial and laboratory environments. This panel ammeter is supplied with mounting brackets to facilitate easy and secure installation.

The device includes a replaceable scale and a front zero-point regulator allowing precise calibration and maintenance. Adhering to international standards such as IP54, DIN 43700, IEC 51, BS 89, as well as UL94 flame retardancy standards, the D48SD ensures safety and compliance in various applications.

This ammeter is especially suited for measuring resistive loads in industrial manufacturing, process control, electrical automation systems, and HVAC installations. Its robust construction and precision make it ideal for demanding environments requiring reliable current monitoring.

The ammeter operates on alternating current with a maximum rating of 100 A. It features a moving iron element and class 1.5 accuracy. Compact 48 mm x 48 mm cutout size with 43 mm depth. Operating temperature range from -25°C to 40°C.

Includes mounting brackets for panel installation. Replaceable scale with front zero calibration. Complies with IP54, DIN, IEC, BS, UL standards. Manufactured in the United Kingdom. Explore the collection of high-quality analogue panel meters by HOBUT at EnvMart, ideal for upgraded industrial control systems and electrical panels.
