RS PRO Analogue Panel Ammeter DC 92mm x 92mm Cutout 1% Accuracy 15mV to 600VDC 186-2509
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | 1% |
| Relative Humidity | Less than 75% annual average (noncondensing) |
| Brand | RS PRO |
| Model | 186-2509 |
| Depth | 67mm |
| Series | RS PRO |
| Maximum Operating Temperature | 65°C |
| Current Type | DC |
| Pointer | Knife-edge type |
| Shock Resistance | 15g for pulse duration 11 milliseconds |
| Overload | 1.2 times nominal voltage (continuous) |
| Cutout Height | 92mm |
| Cutout Width | 92mm |
| Pointer deflection | From 0° to 90° |
| VDE 0100-410 | 2018-10 approved |
| ISO 20653 | 2006-08 |
| Nominal range of use | 15mV to 600VDC |
| HOBUT D96 Series Analogue Voltmeter DC, 92 mm, 92 mmBrand | HOBUT |
Key Features
- Accuracy rated at 1% for precise current measurements.
- Knife-edge type pointer with deflection from 0° to 90° for clear readings.
- Operating temperature range from -10°C to 65°C ensures reliable performance.
- Moulded square polycarbonate case enables sturdy panel mounting.
- Shock resistant to 15g pulse for enhanced durability.
- Overload capacity up to 1.2 times nominal voltage continuously for safety.
- Relative humidity tolerance less than 75% noncondensing for environmental resilience.
- Complies with multiple IEC, VDE, EMC, and CE standards for industrial safety.
Product Description
RS PRO 186-2509 is a DC Analogue Panel Ammeter designed for industrial and automation use, featuring a 92mm x 92mm cutout size and precision 1% accuracy. It measures DC current efficiently over a nominal range of 15mV to 600VDC with a permanent magnet moving coil mechanism, providing accurate average value indications.
The instrument's construction includes a knife-edge type pointer and scales calibrated down to zero with linear scale design. Its moulded polycarbonate square case facilitates robust mounting in control panels, machinery consoles, and switchgear.
Operating temperature spans -10°C to 65°C, with shock resistance at 15g for pulse durations of 11 milliseconds, making it well suited for challenging industrial environments. The ammeter is protected against overload conditions up to 1.2 times its nominal voltage continuously and is designed to function reliably under relative humidity up to 75%, non-condensing.
Conforming to major international standards including IEC 61010, IEC 529, VDE 0100-410:2018-10, and EMC directives 2014/30/EC and 2014/35/EC, this panel meter guarantees compliance and safety. The device is CE certified, IP52 rated, and UL 94 V-0 approved for flame retardance.
This Analogue Panel Ammeter is ideal for electrical automation, process control, laboratory, and manufacturing equipment applications, delivering dependable current measurement in a compact and user-friendly form factor.
Accuracy rated at 1% for precise current measurements. Knife-edge type pointer with deflection from 0° to 90° for clear readings. Operating temperature range from -10°C to 65°C ensures reliable performance. Moulded square polycarbonate case enables sturdy panel mounting.
Shock resistant to 15g pulse for enhanced durability. Overload capacity up to 1.2 times nominal voltage continuously for safety. Relative humidity tolerance less than 75% noncondensing for environmental resilience. Compliance with multiple IEC, VDE, EMC, and CE standards for industrial safety.
Explore the complete range of industrial panel meters and automation control instruments at EnvMart for advanced measurement solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The accuracy is rated at 1%, providing precise current measurements.
It measures DC current over a nominal range of 15mV to 600VDC.
The operating temperature range is from -10°C to 65°C.
It features a knife-edge type pointer with deflection from 0° to 90° for clear readings.
It is shock resistant to 15g for pulse durations of 11 milliseconds.
The overload capacity is up to 1.2 times the nominal voltage continuously.
The cutout dimensions are 92mm x 92mm.
It tolerates relative humidity of less than 75% (non-condensing).
It complies with multiple standards including IEC 61010, IEC 529, VDE 0100-410:2018-10, and EMC directives 2014/30/EC and 2014/35/EC.
The ammeter features a moulded square polycarbonate case for sturdy panel mounting.
It is suitable for electrical automation, process control, laboratory, and manufacturing equipment applications.
The country of origin is India.
