HOBUT Analogue Panel Ammeter 1 A DC, 48 mm x 48 mm, Class 1.5 Moving Coil D48MC

Free Delivery in India | Lowest Global Shipping Charges

HOBUT Analogue Panel Ammeter 1 A DC, 48 mm x 48 mm, Class 1.5 Moving Coil D48MC

Name: HOBUT Analogue Panel Ammeter 1 A DC, 48 mm x 48 mm, Class 1.5 Moving Coil D48MC
Brand: HOBUT
SKU: 154670
Price: 58.82 USD
Availability: InStock



Category Analogue Panel Ammeter Brand HOBUT Condition New

Specifications

Country of Origin	United Kingdom
Brand	HOBUT
Model	D48MC
Depth	43mm
Series	D48MC
Maximum Operating Temperature	40°C
Current Type	DC
Meter Accuracy	Class 1.5
Minimum Operating Temperature	-25°C
Standards/Approvals	UL, IEC, DIN
Cutout Height	48mm
Cutout Width	48mm
Minimum Measurement	0/1A for Shunt 75mV
Maximum Measurement	1 A
Moving Element	Moving Coil
Maximum Ampere Value	1 A
RS PRO Analogue Voltmeter DC, 45 mm, 45 mmBrand	RS PRO

Key Features

The ammeter features a 48x48 mm cutout size for easy panel integration.
It utilizes a moving coil mechanism for accurate analogue readings.
Class 1.5 meter accuracy ensures reliable measurement quality.
Designed to operate in temperatures ranging from -25°C to +40°C.
Complies with UL, IEC, and DIN standards for safety and performance.
The device is shunt-operated requiring an appropriate 75mV shunt for correct usage.
Compact 43 mm depth allows installation in confined spaces.
Flame retardant casing made to UL94V0 specifications provides enhanced safety.

Product Description

HOBUT D48MC Analogue Panel Ammeter is a precision instrument designed for industrial and laboratory use to measure DC current up to 1 A with high accuracy. Featuring a compact 48 mm x 48 mm panel cutout and 43 mm overall depth, this ammeter is ideal for panel mounting in electrical control and automation systems.

The moving coil mechanism combined with Class 1.5 accuracy class provides reliable and consistent readings suitable for process control and instrumentation applications. The meter's flame retardant UL94V0 case enhances safety in various operating environments.

This model operates effectively in ambient temperatures ranging from -25°C to +40°C, ensuring stable performance in diverse industrial conditions. It complies with international standards such as UL, IEC, and DIN, confirming its quality and safety credentials.

All ammeters in this series are shunt-operated and require a separately ordered 75mV shunt for proper operation. The integral scale displays readings with a 90° arc for clear visibility. Terminal covers are available as optional accessories to increase protection in demanding installations.

Manufactured in the United Kingdom, the HOBUT D48MC offers durability, precision, and ease of use for automation, electrical panel building, process control, laboratory, and industrial measurement tasks.

The ammeter features a 48x48 mm cutout with 43 mm depth for compact panel installation. Moving coil design offers high accuracy and reliability. Class 1.5 accuracy meets BS89 and IEC51 standards. Flame retardant UL94V0 case enhances device safety.

Operating temperature range from -25°C to +40°C for versatile applications. Requires a 75mV shunt (ordered separately) for correct operation. Integral 90° scale arc allows easy analogue reading. Terminal covers available as optional protection accessories.

Complies with UL, IEC, and DIN standards ensuring quality and compliance. Suitable for industrial, laboratory, electrical panel, and process control environments. Explore our wide selection of industrial panel meters and automation controls at EnvMart for all your measurement needs.
