Skyworks Solutions Inc Differential Current Shunt Monitor Single 3V-5.5V 5.5mA Supply Current DIP 8-Pin Si8920AC-IP
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Skyworks Solutions Inc |
| Height | 3.44mm |
| Length | 9.9mm |
| Model | Si8920AC-IP |
| Mount Type | Through Hole |
| Output type | Differential |
| Series | Si8920 |
| Maximum Operating Temperature | 125°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| Supply Current | 5.5mA |
| GBP - Gain Bandwidth Product | 950kHz |
Key Features
- Operates from 3V to 5.5V supply voltage suitable for diverse applications.
- Features a low supply current of 5.5mA for energy efficient operation.
- Provides differential analog output with gain bandwidth product of 950kHz.
- Supports two input channels with low offset and gain drift over wide temperature range.
- Designed with galvanic isolation for accurate measurement in noisy environments.
- AEC-Q100 automotive compliant, operating from -40°C to 125°C for robust industrial use.
- Through-hole DIP package with 8 pins and compact dimensions (3.44mm height, 9.9mm length).
- Ideal for motor drive or inverter systems requiring current sensing and fault detection.
Product Description
Skyworks Solutions Inc Si8920AC-IP is an advanced differential current shunt monitor designed for accurate current sensing applications. This single supply device operates from 3V to 5.5V and draws a low supply current of 5.5mA, allowing energy-conscious designs in industrial and automotive systems. The device features galvanic isolation to provide differential analog output signals amplified by 8.1x or 16.2x gain, enabling precise voltage measurement across current shunt resistors without interference from high common mode voltages.
Designed to meet the AEC-Q100 automotive standard, the Si8920AC-IP functions reliably over an extended temperature range from -40°C to 125°C. Its gain bandwidth product of 950kHz supports fast response times, making it well suited for motor drives, inverter controls, and other applications requiring rapid fault detection and load fluctuations monitoring. The device’s robust construction in a through-hole 8-pin DIP package measuring 3.44mm in height and 9.9mm in length simplifies integration into existing PCB layouts.
The low offset and gain drift characteristics ensure consistent accuracy over the device's entire operating temperature range, while its high transient immunity allows it to maintain measurement integrity even in electrically noisy environments. The Si8920 series offers multiple variants, with the Si8920AC-IP specifically providing an input range of ±100 mV in a Gull-Wing DIP-8 configuration, ideal for compact and industrial-grade current sensing solutions.
Operates on a single supply voltage from 3V to 5.5V supporting low voltage systems. Low supply current at 5.5mA enhances energy efficiency suitable for portable and embedded designs. Galvanically isolated differential analog output for safe and precise measurements.
Compliant with AEC-Q100 automotive standards ensuring reliability in harsh environments. Wide operating temperature range from -40°C to 125°C caters to industrial and automotive applications. Compact DIP package with 8 pins eases through-hole mounting and prototyping.
Gain bandwidth product of 950kHz enables fast signal processing for control systems. Manufactured in Thailand with high quality and consistent performance. Used for current measurement in power rails, motor controllers, inverter systems, and load monitoring.
Skyworks Solutions Inc Si8920AC-IP differential current shunt monitor is widely used in industrial, automotive, HVAC, and manufacturing sectors requiring reliable current sensing devices. Its combination of galvanic isolation, wide temperature tolerance, and fast transient response makes it essential for precision current measurement and fault detection. Explore more products in Current Sensing Amplifiers at EnvMart for your electronic design and industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates from a supply voltage of 3V to 5.5V, making it suitable for low voltage systems.
The maximum operating temperature for the Si8920AC-IP is 125°C, allowing it to function reliably in high-temperature environments.
It draws a low supply current of 5.5mA, which enhances energy efficiency in various applications.
This model provides a differential analog output, which is essential for accurate current sensing measurements.
The gain bandwidth product is 950kHz, supporting fast response times for control systems and fault detection.
It supports two input channels, allowing for versatile current sensing applications.
The device is housed in a DIP (Dual In-line Package) format with 8 pins, facilitating through-hole mounting.
This model complies with the AEC-Q100 automotive standard, ensuring reliability in automotive applications.
The dimensions are 3.44mm in height and 9.9mm in length, making it compact for integration into PCB layouts.
It operates effectively in a temperature range from -40°C to 125°C, suitable for both industrial and automotive environments.
This current shunt monitor is ideal for motor drive, inverter systems, and load monitoring in industrial and automotive sectors.
The device is manufactured in Thailand, ensuring consistent performance and quality.
