Skyworks Solutions Inc 2-Channel Digital Isolator 1 Mbps, 2.5 kVrms Isolation Voltage, 5.5 V Supply, 8-Pin SOIC Si8420AB-D-IS
Specifications
| Country of Origin | India |
|---|---|
| Brand | Skyworks Solutions Inc |
| Length | 5mm |
| Model | Si8420AB-D-IS |
| Depth | 1.55mm |
| Width | 4mm |
| Mount Type | Surface |
| Series | Si842 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 4.5mA |
| Number Of Channels | 2 |
| Rise Time | 5ns |
| Power Dissipation | 150mW |
| Supply Voltage | 5.5V |
| Standards/Approvals | CSA, UL, IEC |
| Maximum Forward Voltage | 5.5V |
| Number of Pins | 8 |
| Maximum Data Rate | 1Mbps |
| Propagation Delay Time | 11ns |
| Package Style | SOIC |
Key Features
- This isolator features high electromagnetic immunity for reliable signal isolation.
- It supports a maximum power dissipation of 150 mW for efficient thermal management.
- Contains 2 forward and reverse channels for bidirectional communication.
- Packaged in an 8-pin SOIC surface-mount package with compact dimensions.
- It operates reliably from −40°C up to 125°C operating temperature range.
- The device has a typical propagation delay time of 11 ns and a rise time of 5 ns.
- Maximum input current is 4.5 mA ensuring low power consumption.
- Meets CSA, UL, and IEC standards for quality and safety compliance.
Product Description
Skyworks Solutions Inc Si8420AB-D-IS is a high-performance 2-channel digital isolator designed for precise signal isolation in demanding electronic environments. Operating at a maximum data rate of 1 Mbps and a supply voltage of 5.5 V, this CMOS-based isolator offers robust electrical isolation with a rated isolation voltage of 2.5 kVrms.
The device features low power dissipation of 150 mW, enabling efficient operation without excessive heat generation. Its compact 8-pin SOIC surface mount package with dimensions of approximately 5 mm length, 4 mm width, and 1.55 mm depth allows for space-saving circuit designs.
Featuring high electromagnetic immunity, the Si8420AB-D-IS maintains signal integrity amid electrical noise often present in industrial, communication, and automotive applications. The device supports both forward and reverse channels, enhancing bidirectional data communication capability.
Designed to operate reliably within a temperature range from −40°C to 125°C, this digital isolator ensures stable performance in harsh environments. Key electrical characteristics include a typical propagation delay of 11 ns and a rise time of 5 ns, which contribute to high-speed signal processing.
The device meets key industry standards including CSA, UL, and IEC certifications, providing confidence in safety and quality. It is ideally suited for industrial automation, power supply isolation, data acquisition systems, and embedded digital system applications where signal isolation and noise immunity are critical.
High electromagnetic immunity for reliable isolation. Compact 8-pin SOIC package dimensions. 2 forward and reverse communication channels. Wide operating temperature range from −40°C to 125°C. Low power dissipation of 150 mW.
Compliance with CSA, UL, and IEC standards. Typical propagation delay of 11 ns and rise time of 5 ns. 5.5 V supply voltage with a 2.5 kVrms isolation voltage rating. Explore more advanced digital isolators and related electronic components in our Electronics Components catalogue at EnvMart.
Explore more products in our Digital Isolator ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum data rate of this digital isolator is 1 Mbps.
It has a rated isolation voltage of 2.5 kVrms.
The supply voltage required for operation is 5.5 V.
The package dimensions are approximately 5 mm in length, 4 mm in width, and 1.55 mm in depth.
The typical propagation delay time is 11 ns.
It operates reliably within a temperature range from −40°C to 125°C.
This digital isolator supports 2 channels for bidirectional communication.
The maximum input current is 4.5 mA, ensuring low power consumption.
It meets CSA, UL, and IEC standards for quality and safety compliance.
The rise time is 5 ns, contributing to high-speed signal processing.
It is designed for surface mounting in an 8-pin SOIC package.
It is suitable for industrial automation, power supply isolation, and data acquisition systems.
