Keithley Digital Bench Power Supply 1-Output 0 V to 80 V, 1.08 kW, 40.5 A Max 2260B-80-40

Keithley 2260B-80-40 digital bench power supply is a high-performance programmable DC power supply delivering up to 1.08 kW of power with a maximum output voltage of 80 V and current of 40.5 A through a single output channel. This digital supply supports a wide voltage and current range providing constant power output, ideal for a variety of demanding applications including environmental test, stress testing, accelerated life tests, LED and high-power component testing, automotive testing, battery research, and production testing.

The unit features programmable voltage or current rise and fall times that protect devices from inrush current, ensuring safe and reliable operation. The constant current priority setting minimizes voltage and current overshoot, particularly beneficial when powering sensitive LED devices. Its programmable output resistance capability allows simulation of battery output characteristics, enhancing its versatility in testing scenarios.

Connectivity options include analog control, USB, LAN, and optional GPIB interfaces, enabling automated control and integration into test systems. The compact form factor fits two 214 mm wide units into a standard rack width, saving valuable bench and system space. Units can be combined in series or parallel configurations for increased voltage and current outputs, with the master unit displaying total system voltage and current readings.

Constructed to meet industrial standards and RoHS compliance, it operates within a temperature range of 0°C to 50°C, ensuring reliable performance in laboratory and industrial environments. Physical dimensions are 124 mm height, 71 mm width, and 350 mm depth. The product is manufactured in Taiwan, Province of China.

This power supply is supported by KickStart software, providing enhanced functionality and ease of use. The three-year warranty and the availability of software updates emphasize its quality and longevity. Suitable for industrial, laboratory, manufacturing, and automotive sectors, it offers precision and flexibility in power testing applications.

High power density with single output channel for versatile applications. Programmable voltage and current rise/fall times prevent inrush damage. Constant current priority to reduce overshoot during LED powering. Programmable output resistance simulates battery characteristics.

Multiple control interfaces including USB, LAN, and optional GPIB. Compact design fits standard rack widths, saving bench space. Ability to combine units for higher voltage or current output. RoHS compliant for environmentally responsible manufacturing.

Supports industrial, laboratory, and production testing requirements. Includes three-year warranty and KickStart software support. Explore more Bench Power Supplies at EnvMart for reliable test and measurement solutions.
