Schneider Electric Power Relay 110V DC Coil 8A Switching Current 4PDT RXM4AB2FD
Specifications
| Country of Origin | China |
|---|---|
| Brand | Schneider Electric |
| Height | 27mm |
| Length | 21mm |
| Model | RXM4AB2FD |
| Width | 47.7mm |
| Contact Material | Silver Alloy |
| Series | RXM |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | 4PDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Plug-In |
| Standards/Approvals | CE, CSA |
| Coil Resistance | 13.4kΩ |
| Coil Voltage | 110V dc |
| Switching DC Voltage | 28V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 900mW |
Key Features
- The relay has a compact miniature RXM series design with LED indicator.
- It operates within a temperature range of -40°C to 55°C.
- Plug-in terminal type ensures easy installation and integration.
- Silver alloy contact material provides durable and efficient electrical connectivity.
- Coil resistance is precisely 13.4 kΩ with a coil power consumption of 900 mW.
- This relay supports switching DC voltage up to 28V and AC voltage up to 250V.
- The relay measures 47.7 mm width, 27 mm height, and 21 mm length.
- Suitable for industrial, HVAC, machine equipment, and electrical enclosure applications.
Product Description
Schneider Electric RXM4AB2FD Power Relay is a compact miniature relay designed for industrial applications, including machine equipment, HVAC systems, and electrical enclosures. It features a 110V DC coil and 8A switching current with a 4PDT contact configuration, enabling reliable switching of electrical circuits.
Part of the RXM series, this relay includes a mechanical indicator and LED for easy status monitoring. Its plug-in terminal type simplifies installation and programming without adjustments required for most standard applications.
The relay operates efficiently between -40°C and 55°C ambient temperature and incorporates a silver alloy contact material to ensure low electrical resistance and durability. The coil resistance is calibrated at 13.4 kΩ, with coil power consumption of 900 mW.
Designed to switch loads of up to 28V DC and 250V AC, this relay is suitable for a wide range of electrical switching tasks in industrial automation, HVAC controls, and building equipment systems.
With dimensions of 47.7 mm width, 27 mm height, and 21 mm length, the relay's compact size allows easy integration into tight spaces. The product complies with CE and CSA quality standards.
The relay's non-latching design makes it ideal for push-button applications and microcontroller input buttons. It is robust and hard-wearing, guaranteeing long operational life in demanding environments. Provides easy installation and LED status visualization for user convenience.
Compact RXM series design fits diverse industrial electrical enclosures. Silver alloy contacts provide efficient conductivity and durability. Designed to handle high switching currents up to 8A with safety certifications.
Schneider Electric power relays like RXM4AB2FD are widely used in industrial automation, laboratory instrumentation, commercial HVAC systems, and manufacturing equipment. They provide reliable circuit switching with minimal maintenance, meeting modern industrial requirements.
Explore more Schneider Electric Power Relays and control components at EnvMart, trusted for quality and industrial performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power relay has a switching current capacity of 8A.
This model operates with a coil voltage of 110V DC.
The relay measures 47.7 mm in width, 27 mm in height, and 21 mm in length.
It features a 4PDT (four pole double throw) contact configuration.
The relay operates efficiently within a temperature range of -40°C to 55°C.
It uses a plug-in terminal type for easy installation and integration.
The coil resistance is precisely 13.4 kΩ.
The coil power consumption is 900 mW.
It supports switching DC voltage up to 28V and AC voltage up to 250V.
The contacts are made from silver alloy, providing efficient conductivity.
The product complies with CE and CSA quality standards.
This relay is suitable for industrial automation, HVAC systems, and electrical enclosures.
