Mentor GmbH Rigid 1-Way Straight PCB Mounted Yellow LED Light Pipe 15mm 1294.1001

Mentor GmbH model 1294.1001 is a rigid, 1-way, straight LED light pipe with a 15 mm length designed for PCB mounting. It serves as a vertical light guide transmitting light from a PCB-mounted yellow LED with a clear round lens to the user interface with minimal luminance loss and no light bleed. Its design supports up to three SMD LEDs with 0805 or smaller footprints, enabling applications such as bi-colour or tri-colour displays.

The light pipe’s round head features a 3 mm outside diameter and a 2.2 mm inside diameter. Mounting is achieved via push-fit lugs that secure the pipe to the printed circuit board close to the LED source. This ensures effective light injection and precise indication in electronic components.

Constructed from durable rigid material suitable for harsh industrial or laboratory environments, it operates reliably in ambient temperatures between -40°C and +85°C. Compliance with RoHS standards confirms environmental safety and restricted hazardous substances.

Mentor GmbH LED light pipes are widely used in electronic assemblies, display units, instrumentation panels, and control interfaces, offering excellent optical transmission with high ESD protection, making them suitable for engineering, manufacturing, and electrical installation applications.

Rigid construction ensures durability and precise light guidance. Measures 15 mm in length with a round shape having a 3 mm outside diameter. Suitable for use with PCB-mounted LEDs, enhancing display visibility. Designed to accommodate up to 3 SMD LEDs with 0805 footprint or smaller.

Features a clear lens with yellow LED color for effective light indication. Push-fit lug mounting allows secure attachment to PCBs. Ambient operating temperature ranges from -40°C to +85°C. Complies with RoHS standards for environmental safety.

Manufactured in Germany ensuring high-quality standards. Provides high ESD protection and minimizes light bleed between adjacent elements. Explore additional LED Light Pipe options and related Mentor GmbH products on EnvMart for diverse industrial and electronic display solutions.
