Mentor GmbH Press-In 30-Way Right Angle Rigid LED Light Pipe Clear 1296.2013

Mentor GmbH 1296.2013 Press-In 30-Way Right Angle Rigid LED Light Pipe is engineered to transmit light efficiently from surface mount LEDs to user interfaces across a variety of electronic and industrial applications.

This product features a rigid light pipe construction with a right angle orientation, ideal for compact PCB layouts where space and precise light direction are critical.

Comprising 30 individual light pipes arranged in 3 rows and 1 column, each with a dome shape and 1.95 mm outside diameter, this light guide design ensures uniform light diffusion with minimal luminance loss and no bleed between adjacent elements.

The press-in mount type allows for secure and easy installation directly onto circuit boards, using push-fit lugs for fast assembly.

Manufactured under UL94 standards from clear polycarbonate material, the light pipe offers flame retardancy and dependable performance across ambient temperatures ranging from -40 degrees Celsius to +85 degrees Celsius.

This light pipe is specialized for use with SMD LEDs, effectively channeling their light output to the device indicator or panel without including LEDs themselves. Industrial and commercial uses include electronic component displays, control panels, and indicators in laboratories, manufacturing equipment, and consumer electronics.

The product delivers high ESD protection combined with simple mechanical installation. Its tri-level horizontal light pipe arrangement offers versatile design options for multiple indicator configurations. The clear polycarbonate construction ensures durability and excellent optical clarity.

Package contents typically include the LED Light Pipe set as described. Explore more in the Electronics & Electricals category under LED & Lights at EnvMart for comprehensive solutions including related LED components and lighting accessories.
