Microchip Operational Amplifier 10 MHz 8-Pin PDIP 5.5V MCP6022-I/P
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 3.3mm |
| Length | 9.27mm |
| Model | MCP6022-I/P |
| Width | 6.35mm |
| Mount Type | Through Hole |
| Series | MCP6022 |
| Output Current | 30mA |
| Maximum Operating Temperature | 85°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 10MHz |
| Input Bias Current | 1 pA |
| Slew Rate | 7V/μs |
| MCP6022-E/P Microchip, Operational Amplifier, 10 MHz, 8-Pin 5.5V PDIPBrand | Microchip |
Key Features
- Through-hole mount type suitable for PCB integration.
- Dual channel amplifier with 8-pin configuration.
- Input offset voltage of ±500 µV ensures precision operation.
- Low input bias current of 1 pA reduces signal distortion.
- Supports supply voltage range from 3V minimum to 5.5V maximum.
- Slew rate of 7 V/μs allows fast signal response.
- Operating temperature range from -40°C to 85°C for industrial applications.
- Output current capacity up to 30 mA.
Product Description
Microchip MCP6022-I/P is a dual-channel operational amplifier designed for precision signal processing applications. Featuring a gain bandwidth product of 10 MHz, the amplifier provides stable and accurate amplification in electronic circuits. Packaged in an 8-pin PDIP, this device supports through-hole mounting, enabling easy integration into PCB designs.
Operating at a supply voltage between 3V and 5.5V, the MCP6022-I/P maintains a low input offset voltage of ±500 µV and an extremely low input bias current of 1 pA. These characteristics reduce signal errors and ensure high fidelity in analog signal amplification. Its 7 V/μs slew rate allows the amplifier to respond quickly to fast-changing input signals.
With an output current capacity of 30 mA, it supports a wide range of load conditions. The device operates reliably within an industrial temperature range from -40°C to 85°C, making it suitable for harsh environments. Compliance with RoHS standards certifies the product as environmentally friendly.
Typical use cases for the MCP6022-I/P operational amplifier include industrial process control, medical instruments, precision sensor interfaces, data acquisition systems, and communication equipment. It finds applications in electronic manufacturing, laboratory instrumentation, and embedded system designs requiring high-precision analog signal handling.
Through-hole mount type suitable for PCB integration. Dual channel amplifier with 8-pin configuration. Input offset voltage of ±500 µV ensures precision operation. Low input bias current of 1 pA reduces signal distortion.
Supports supply voltage range from 3V minimum to 5.5V maximum. Slew rate of 7 V/μs allows fast signal response. Operating temperature range from -40°C to 85°C for industrial applications. Output current capacity up to 30 mA.
RoHS compliant meeting environmental standards.
Explore more Microchip Operational Amplifiers and related electronic components in the Electronics & Electricals category at EnvMart for all your industrial and laboratory requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP6022-I/P has a gain bandwidth product of 10 MHz, providing stable and accurate amplification in electronic circuits.
This operational amplifier features an input offset voltage of ±500 µV, ensuring precision operation in signal processing applications.
It supports a supply voltage range from a minimum of 3V to a maximum of 5.5V, allowing flexibility in various applications.
The output current capacity of the MCP6022-I/P is up to 30 mA, accommodating a wide range of load conditions.
This unit operates reliably within an industrial temperature range from -40°C to 85°C, making it suitable for harsh environments.
The slew rate for this operational amplifier is 7 V/μs, allowing it to respond quickly to fast-changing input signals.
The MCP6022-I/P features an 8-pin PDIP configuration, suitable for through-hole mounting on PCBs.
This operational amplifier has a low input bias current of 1 pA, which helps reduce signal distortion.
Yes, this model is RoHS compliant, meeting environmental standards for hazardous substances.
Typical applications include industrial process control, medical instruments, precision sensor interfaces, and data acquisition systems.
The MCP6022-I/P has dimensions of 9.27 mm in length, 6.35 mm in width, and a height of 3.3 mm.
This operational amplifier supports through-hole mounting, making it easy to integrate into PCB designs.
