KEMET SPST Through Hole Reed Switch 500 mA 140 V AC TRS5-75BLRU

KEMET TRS5-75BLRU SPST Through Hole Reed Switch delivers high reliability and consistent performance for switching applications up to 500 mA and 140 V AC voltage rating. This component is engineered for on/off operations with high-speed response and long operational life, making it suitable for industrial and commercial electronic assemblies.

The device features a single-pole, single-throw (SPST) contact configuration with nickel iron alloy contacts that provide low contact resistance of 150 mΩ, enabling efficient electrical conduction and minimizing power loss. Its through hole mounting type and cable terminal ensure robust installation on printed circuit boards or other assemblies.

Compact and lightweight, the reed switch measures 8.2 mm in width, 5 mm in length, and 20 mm in depth, allowing for easy integration even in space-constrained applications. It operates reliably across a wide temperature range from -20°C to 130°C, resisting environmental factors such as dust, corrosion, and explosions, thus enhancing durability in harsh conditions.

The TRS5-75BLRU series complies with global standards including REACH, UL, CSA, and RoHS, guaranteeing conformity to regulatory and safety requirements. Typical industrial use cases include temperature detection, overheat monitoring for electrical appliances, heater controls in household devices, defrosting mechanisms in HVAC systems, and automotive fan control systems.

Designed for simple and compact circuit designs, this reed switch is an excellent choice for engineers requiring durable and accurate switching components. Its precision and environmental resilience make it a dependable part for manufacturing, HVAC, automotive, and agricultural electrical systems.

Features SPST contact configuration allowing single-pole, single-throw switching. Maximum switching current rated at 500 mA ensuring suitable performance for low power circuits. Maximum switching voltage of 140 V AC ideal for various electrical applications.

Compact dimensions with width 8.2 mm, length 5 mm, and depth 20 mm for easy PCB integration. Constructed with nickel iron alloy contacts for durable and low resistance performance. Through hole mount type facilitates stable and secure soldering to boards.

Operational temperature range from -20°C to 130°C suitable for diverse environments. Compliance with industry standards including REACH, UL, CSA, and RoHS guarantees quality and safety. High reliability with long operational life and excellent environmental durability.

Explore more KEMET Reed Switches and other precision electrical components at EnvMart for your industrial and electronic project requirements.
