Siemens SIWAREX WL Series Stainless Steel Compression Load Cell 50kg, IP68, Screw Terminal 7MH5106-2PD00
Specifications
| Country of Origin | China |
|---|---|
| Brand | Siemens |
| Length | 120mm |
| Model | 7MH5106-2PD00 |
| IP Rating | IP68 |
| Housing Material | Stainless Steel |
| Series | SIWAREX WL |
| Maximum Operating Temperature | 65°C |
| Minimum Operating Temperature | -35°C |
| Terminal type | Screw |
| Maximum dc Voltage | 10V dc |
| Standards/Approvals | OIML R60 |
| Force Measured | Compression |
| Maximum Force/Load Measurement | 50kg |
Key Features
- The load cell measures compression forces with a rated load capacity of 50kg.
- It features a robust stainless steel housing suitable for harsh environments.
- IP68 ingress protection ensures water and dust resistance for reliable performance.
- Operating temperature ranges from -35°C to 65°C for versatile use.
- Connection is provided via screw terminals with a 3-meter 4-conductor cable.
- Complies with OIML R60 accuracy standard, class C3.
- Maximum DC voltage rating is 10V for safe operation.
- Integral overload protection embedded for rated load up to 13t.
Product Description
Siemens 7MH5106-2PD00 SIWAREX WL Series Load Cell is a high-quality compression sensor designed for precise weighing applications in industrial environments. Constructed with a stainless steel double bending beam, it provides exceptional durability and performance under demanding conditions. The sensor includes four strain gauges and offers excellent protection rating of IP68 making it suitable for wet and dusty environments.
The load cell supports a maximum force measurement of 50kg with accuracy class C3 adhering to OIML R60 standards. It operates safely within a temperature range of -35°C to 65°C and a maximum DC voltage of 10V. The 120mm length and screw terminal connections with a 3m 4-conductor cable allow for secure and flexible installation options.
This Siemens load cell model 7MH5106-2PD00 is ideal for industrial weighing tasks such as small-scale container and platform scales, providing high precision with a measurement resolution of up to 15,000 divisions. Integral overload protection ensures reliability and longevity of the sensor.
Engineered for use in automation, manufacturing, laboratory, and material handling industries, the robust design of the SIWAREX WL series load cells makes them a dependable choice where accurate force measurement and environmental resistance are essential.
The load cell measures compression forces with a rated load capacity of 50kg. It features a robust stainless steel housing suitable for harsh environments. IP68 ingress protection ensures water and dust resistance for reliable performance.
Operating temperature ranges from -35°C to 65°C for versatile use. Connection is provided via screw terminals with a 3-meter 4-conductor cable. Complies with OIML R60 accuracy standard, class C3. Maximum DC voltage rating is 10V for safe operation.
Length of the load cell is 120mm facilitating easy installation. Integral overload protection embedded for rated load up to 13t.
This product is made in China and is ideal for integration with SIWAREX weighing electronics and industrial automation systems. EnvMart offers Siemens SIWAREX Load Cells as a precise solution to meet demanding industrial weighing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a maximum load capacity of 50kg for measuring compression forces.
The load cell features an IP68 ingress protection rating, ensuring it is resistant to water and dust.
It operates safely within a temperature range of -35°C to 65°C.
Connection is provided via screw terminals with a 3-meter 4-conductor cable.
It complies with the OIML R60 accuracy standard, class C3.
The length of the load cell is 120mm, facilitating easy installation.
The maximum DC voltage rating for this load cell is 10V.
It is ideal for industrial weighing tasks, such as small-scale container and platform scales.
This model measures compression forces.
Yes, it features integral overload protection for rated loads up to 13t.
This product is made in China.
