Europa Miniature Circuit Breaker 3-Pole 25A Type C 400V AC 10 kA Breaking Capacity EUC3P

Europa EUC3P Miniature Circuit Breaker (MCB), model EUC3P, is a robust 3-pole device designed to provide effective overcurrent protection for low voltage electrical circuits up to 25A rating. Operating at a rated AC voltage of 400V, this MCB features a Type C tripping characteristic suitable for both residential and industrial electrical installations.

The device is engineered for safe and reliable circuit interruption with a breaking capacity of 10 kA. It mounts easily on a standard 35mm DIN rail, facilitating convenient integration into consumer units and distribution panels.

Measuring 78mm in width, 87mm in depth, and 54mm in height, the compact form factor maximizes panel space efficiency. The toggle switch actuator allows for intuitive manual reset operations during fault clearance.

Europa's EUC3P MCB supports terminal cable sizes ranging from 1mm² to 25mm², accommodating a wide array of wiring needs. Its IP20 ingress protection rating safeguards against accidental contact and solid foreign objects, enhancing user safety.

This product complies fully with stringent international safety standards IEC 60898 and EN 60898, bearing CE and SEMKO certifications to ensure quality and reliability. The unit is manufactured in China under strict quality controls.

Suitable for mounting on 35mm DIN rail for easy installation. Rated operating voltage of 400V AC ensures compatibility with standard electrical systems. Toggle switch reset actuator type enables quick manual intervention.

Compact dimensions of 78mm width, 87mm depth, and 54mm height save panel space. Tripping characteristic Type C provides efficient protection against overloads and short circuits. IP20 rating offers protection against finger access and solid foreign objects.

Terminal capacity supports cables from 1mm² to 25mm² for versatile wiring. Conforms to international standards IEC 60898 and EN 60898, certified with CE and SEMKO approvals.

Ideal for use in industrial, commercial, and residential electrical distribution systems requiring dependable circuit protection and compliance with safety regulations. Explore more Europa circuit breakers and electrical protection devices in EnvMart's extensive catalog.
