Eaton xEffect Miniature Circuit Breaker, 2-Pole, 20A, Type D, 415V AC, 10 kA Breaking Capacity 102191 FAZ-D20/2-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 102191 FAZ-D20/2-NA |
| Depth | 76mm |
| IP Rating | IP20 |
| Width | 105mm |
| Mount Type | DIN Rail |
| Current Rating | 20A |
| Series | xEffect |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Rated AC Voltage | 415V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Two-pole design suitable for 415V AC systems.
- Offers 10 kA breaking capacity for effective short circuit interruption.
- Features a thermal magnetic tripping mechanism for dependable performance.
- DIN rail mountable for easy installation.
- Equipped with a toggle switch reset actuator.
- Screw-type terminal for secure connections.
- IP20 rated for protection against solid objects.
- Suitable for supplementary protection in control panel applications.
Product Description
The Eaton 102191 FAZ-D20/2-NA xEffect Miniature Circuit Breaker is a high-quality, reliable device designed for industrial and commercial electrical protection. This 2-pole circuit breaker supports a current rating of 20A with Type D tripping characteristics, suitable for 415V AC power systems. It delivers a breaking capacity of 10 kA, ensuring effective interruption of short circuits to safeguard electrical installations.
Its compact design with a width of 105mm and depth of 76mm allows for efficient use in control panels. The breaker features a thermal magnetic tripping mechanism providing six levels of over-current protection, ensuring safety and reliability in operation.
Equipped with a toggle switch reset actuator, the breaker can be easily reset after tripping. The screw terminal type assures secure electrical connections, while the DIN rail mounting simplifies installation. The IP20 rating protects the device from access to hazardous parts and ingress of solid objects larger than 12mm, making it suitable for industrial environments.
This miniature circuit breaker offers short circuit current limiting capabilities to reduce damage from electrical faults. The trip-free design prevents manual override, enhancing safety. Red or green indicator lights clearly show contact positions for operational status monitoring.
Two-pole design suitable for 415V AC systems. 20A rated current for various applications. Type D tripping characteristic for specific protection requirements. 10 kA breaking capacity for reliable short circuit interruption.
DIN rail mount for convenient panel installation. Screw terminal type for secure wiring. Toggle switch reset actuator for simple operation. IP20 rating provides adequate protection in typical industrial environments. Thermal magnetic trip mechanism ensures dependable operation.
This Eaton miniature circuit breaker is ideal for industrial, manufacturing, laboratory, and commercial installations requiring supplemental protection of electrical circuits. It ensures system reliability while protecting personnel and equipment from electrical faults. The product is part of Eaton's xEffect series known for its dependable and compact circuit protection solutions.
Browse more Miniature Circuit Breakers and Eaton products at EnvMart for quality and safety in electrical automation and control systems.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 20A, making it suitable for various applications in electrical systems.
It features a breaking capacity of 10 kA, which ensures effective interruption of short circuits.
The circuit breaker is rated for 415V AC, suitable for use in compatible electrical systems.
This unit is designed for DIN rail mounting, which simplifies installation in control panels.
It utilizes a thermal magnetic tripping mechanism, providing reliable over-current protection.
It has an IP20 rating, which protects against access to hazardous parts and solid objects larger than 12mm.
The dimensions of this model are 105mm in width and 76mm in depth.
It is equipped with a toggle switch reset actuator for easy operation after tripping.
This is a 2-pole circuit breaker, suitable for specific electrical configurations.
It is ideal for industrial, manufacturing, laboratory, and commercial installations requiring supplemental protection of electrical circuits.
It features a screw terminal type, ensuring secure electrical connections.
This model is part of the xEffect series, known for its compact and dependable circuit protection solutions.
