Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 1.5A, Type D, 240V AC, 48V DC, 10 kA Breaking 102099 FAZ-D1,5/1-NA
Specifications
| Country of Origin | India |
|---|---|
| Range | xEffect |
| Brand | Eaton |
| Model | 102099 FAZ-D1,5/1-NA |
| Depth | 73mm |
| IP Rating | IP20 |
| Width | 85mm |
| Mount Type | DIN Rail |
| Current Rating | 1.5A |
| Series | FAZ |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Rated AC Voltage | 240V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Supports AC voltage rating of 240V and DC voltage rating of 48V.
- Features a breaking capacity of 10 kA ensuring effective short circuit interruption.
- DIN rail mount type suitable for control panel applications.
- Toggle switch with thermal-magnetic tripping mechanism for enhanced safety.
- IP20 rated with screw-type terminals for secure wiring.
- Compact dimensions with 85mm width and 73mm depth.
- Instantaneous break time and trip-free handle mechanism.
- Reliable indication of contact position via red or green light.
Product Description
Eaton 102099 FAZ-D1,5/1-NA is a high-quality miniature circuit breaker in the xEffect range designed for industrial and commercial electrical protection. This 1-pole breaker operates with a current rating of 1.5A and features a Type D tripping characteristic ideal for protecting circuits with high inrush currents.
Rated for 240V AC and 48V DC, it delivers a breaking capacity of 10 kA, providing reliable short circuit interruption to safeguard electrical systems from damage. The circuit breaker mounts on standard DIN rails, enabling straightforward integration into control panels.
Equipped with a toggle switch actuator and thermal-magnetic tripping mechanism, this breaker ensures quick response to overcurrent and short circuits while preventing defeat by handle manipulation with a trip-free design. The unit includes screw terminal connections for secure wiring and is protected against solid foreign objects with an IP20 rating.
Instantaneous break time enhances safety, and the toggle can be sealed in both ON and OFF positions where required. Contact status is clearly indicated by red or green light, ensuring easy monitoring of breaker state.
This Eaton FAZ series circuit breaker is suitable for supplementary protection applications in industrial manufacturing, electrical panels, automation systems, and general electrical installations requiring dependable overcurrent protection.
Supports current limiting design to reduce let-through energy on short circuits. Rated currents up to 63A available in the FAZ series for versatility. Robust construction ensures long service life and safe operation. Complies with industrial DIN rail mounting standards.
Easy installation and reliable supplementary protective functionality. Explore more Miniature Circuit Breakers and electrical automation products in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 1.5A.
It features a breaking capacity of 10 kA, providing effective short circuit interruption.
The breaker supports an AC voltage rating of 240V and a DC voltage rating of 48V.
It is designed for DIN rail mounting, making it suitable for integration into control panels.
It utilizes a thermal-magnetic tripping mechanism for enhanced safety and quick response to overcurrent.
The unit has an IP20 rating, protecting it against solid foreign objects.
The dimensions are 85mm in width and 73mm in depth.
It features screw-type terminals for secure wiring connections.
Contact position is indicated by red or green lights, allowing for easy monitoring.
It has a Type D tripping characteristic, suitable for circuits with high inrush currents.
The break time is instantaneous, enhancing safety during operation.
The Eaton FAZ miniature circuit breaker is manufactured in India.
