Eaton xEffect Miniature Circuit Breaker 2-Pole 5A Type C 415V AC 10 kA Breaking Capacity 102163 FAZ-C5/2-NA

Eaton 102163 FAZ-C5/2-NA miniature circuit breaker is a high-quality 2-pole protection device designed for use in industrial, commercial, and electrical automation control panel applications. Rated for 5 amperes and Type C tripping characteristics, this circuit breaker protects circuits operating at up to 415 volts AC with a breaking capacity of 10 kiloamperes, ensuring robust interruption of short circuits.

The breaker is designed for DIN Rail mounting and features screw terminal connections for secure wiring. Its thermal magnetic tripping mechanism provides both thermal protection from overloads and magnetic protection from short circuits, offering dependable operation and safety.

The instantaneous break time characteristic allows rapid response to fault conditions, minimizing damage. The toggle switch actuator can be sealed in either the ON or OFF position and features a trip-free design that prevents manual override of tripping by holding the handle.

The compact design with a width of 105mm and depth of 76mm makes it suitable for space-conscious panel installations. An IP20 rating safeguards against access of fingers and solid objects, suitable for indoor installations.

The device includes a visual red or green contact position indicator, enhancing operational clarity during maintenance or inspection. It serves well as supplementary protection in various electrical setups.

Part of Eaton’s xEffect series, known for incorporating current limiting design, this breaker effectively reduces let-through energy during short circuits, protecting downstream equipment and wiring. Eaton’s legacy of quality and reliability ensures long-term, safe operation.

This Miniature Circuit Breaker is ideal for industrial manufacturing, electrical distribution, HVAC systems, commercial electrical panels, and laboratory electrical setups seeking reliable circuit protection.

Designed for DIN Rail mounting with screw terminals. Rated AC voltage of 415V suitable for industrial control panels. Thermal magnetic tripping mechanism ensures reliable protection. Instantaneous break time for rapid fault response.

Toggle switch actuator type with trip-free design for safety. Compact dimensions of 105mm width and 76mm depth. IP20 rated enclosure for basic protection against solid objects. Red or green indication light shows contact position.

Suitable for supplementary protection in electrical installations. Part of Eaton's reliable xEffect series offering current limiting design to reduce let-through energy. Explore more high-quality circuit breakers in the Electronics & Electricals category at EnvMart for trusted industrial and commercial electrical solutions.
