NKK Switches Illuminated Push Button Switch On-On SPDT Through Hole Green LED 30V dc 250V ac UB15SKW035F

NKK Switches UB15SKW035F is a high-quality illuminated push button switch designed for industrial and electronic applications requiring reliable On-On switching functionality with SPDT contact configuration. This push button switch is part of the UB series, known for combining robust construction with versatile mounting options.

The switch operates at low contact voltages of 30 V dc and can handle contact AC voltages up to 250 V ac, providing flexible use in control circuits and electrical panels. It supports a switch contact current of 5A, suited for standard load switching requirements. The plunger style actuator delivers ergonomic operation with clear tactile feedback.

Featuring a green LED illumination, this switch provides visual status indication making it ideal for use in automation, electrical equipment, and industrial control applications. Its through-hole mounting and PC pin terminal type facilitate secure and reliable connection to printed circuit boards.

The device withstands operating temperatures from -25°C up to +50°C, allowing for use in a wide range of ambient conditions. Compliance with CSA and UL 94 V-0 flame retardant standards ensures it meets stringent quality and safety regulations.

This switch series allows options for square or rectangular caps with full-face or spot illumination, allowing customized visual effects. Non-illuminated variants are also available in the UB series for applications where LED indicators are not required.

Manufactured in the Philippines, the UB15SKW035F push button switch represents a durable and reliable choice for industrial, laboratory, automation, HVAC, and manufacturing sectors, facilitating precise control and enhanced operator interface. The compact snap-in design along with short body length enables usage in tight and compact assemblies.

Key features include robust electrical ratings, versatile mounting styles, and multiple LED color options for custom signalling requirements. This product is essential for engineers and technicians seeking a dependable illuminated push button switch to integrate into electronic control panels and equipment.

The switch features a green LED illumination for clear visual indication. Designed for through-hole mounting with PC pin terminals ensuring easy PCB integration. Operates reliably within -25°C to 50°C temperature range. Supports contact voltages up to 30 V dc and 250 V ac for versatile electrical applications.

Switch contact current rating is up to 5A suitable for various control circuits. The plunger actuator style provides precise tactile feedback for user control. Meets CSA and UL 94 V-0 standards ensuring safety and quality compliance.

Compact design suits applications requiring snap-in and PCB mounted switches with LED illumination. Manufactured in Philippines with high-quality materials for durability. Explore more in EnvMart's Electronics & Electricals Push Button Switches to find compatible components for your projects.
