Idec Illuminated Push Button Switch Panel Mount Momentary On-Off 30 V dc 250 V ac Round Actuator LBW6L-M1T64S

Idec LBW6L-M1T64S is a precision illuminated push button switch designed for panel mounting with momentary On-Off switch operation. This model features a black round actuator providing smooth and reliable tactile feedback.

It is suitable for use in electrical, automation, and control applications where a robust interface is needed. The switch supports contact voltages up to 30 V dc and 250 V ac, making it compatible with a wide range of industrial circuits.

The push button's illumination is ensured by an integrated LED, offering bright and clear indication to operators, thus increasing safety and ease of use in dimly lit environments. The flush bezel projects only 2 mm from the panel surface, achieving a compact and professional finish with a small panel depth of 27.9 mm.

The product is rated for protection to IP40 and IP67 standards, ensuring resistance against dust and temporary immersion in water. Furthermore, the switch can operate reliably at a maximum temperature of 120°C, suitable for demanding industrial environments.

Gold-clad cross-bar contacts or high-capacity silver contacts provide stable conductivity and long service life, with a contact current rating of 18 mA. The solder terminal type allows for secure and straightforward soldered connections in control panels or PCB assemblies.

Compliant with CSA and UL standards, this switch is manufactured in Japan, emphasizing quality and safety. The legend on the lens can be customized by engraving on a marking plate or clear film, enabling tailored labeling for specific applications.

This illuminated push button switch finds extensive use in industrial equipment, machinery control panels, automation systems, and electrical distribution panels. It ensures reliable user interaction and clear status indication in commercial and industrial settings.

Explore more Push Button Switches and components for diverse automation and electrical control requirements in the Electronics & Electricals category on EnvMart. Features a black round actuator for easy identification and operation.

Illumination is provided by bright and clear LED technology for enhanced visibility. Designed with IP40 and IP67 ratings ensuring protection against dust and water ingress. Flush bezel design projects only 2 mm from panel front, providing a sleek installation.

Maximum operating temperature is rated at 120°C for reliable performance in demanding environments. Gold-clad cross-bar contacts and high-capacity silver contacts ensure durability and low contact resistance. Switch contact current rated at 18mA supporting low power control circuits.

Terminals designed for solder connection allowing secure electrical connections. Standards met include CSA and UL for global compliance and safety assurance. Engraving can be applied on marking plates or clear films placed in the lens for custom legends.
