Myrra 18 V ac 2 Output Through Hole PCB Transformer 1.5 VA 44095

Free Delivery in India | Lowest Global Shipping Charges

Myrra 18 V ac 2 Output Through Hole PCB Transformer 1.5 VA 44095

Name: Myrra 18 V ac 2 Output Through Hole PCB Transformer 1.5 VA 44095
Brand: Myrra
SKU: 237755
Price: 6.75 USD
Availability: InStock



Category PCB Transformer Brand Myrra Condition New

Specifications

Country of Origin	France
Brand	Myrra
Length	32.6mm
Model	44095
Depth	24.3mm
Gross Weight	80g
Width	27.6mm
Mount Type	Through Hole
Maximum Operating Temperature	70°C
Number of outputs	2
Winding Type	Single Primary, Dual Secondary
Number of Pins	6
Primary Voltage	230 V ac
Secondary Voltage	18 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
PCB Transformer Current	42mA
Myrra 18 V ac 2 Output Through Hole PCB Transformer, EN 61558-2-6 1 VABrand	Myrra
Block 18V ac 2 Output Through Hole PCB Transformer, 1.5VABrand	Block

Key Features

Features dual secondary outputs with nominal secondary voltage of 18 V ac.
Operates at a primary voltage of 230 V ac, suitable for European grid applications.
Compact physical dimensions measuring 32.6mm length, 27.6mm width, and 24.3mm depth.
Designed for 42mA current with single primary and dual secondary winding type.
Maximum operating temperature rated at 70°C, with frequency range from 50Hz to 60Hz.
Constructed for reliable performance with encapsulated vacuum resin filling for aging resistance.
Complies with UL 94-V0, VDE 0551, and IEC 742 standards but lacks specific certifications.
Weighs approximately 80 grams, optimized for PCB mounting using through hole type installation.

Product Description

Myrra 44095 PCB Transformer with 18 V ac secondary voltage and 1.5 VA power rating is engineered for safe, reliable operation on printed circuit boards. This through hole mounted transformer provides two separate outputs, making it suitable for varied industrial and electronic applications.

The transformer operates at an input of 230 V ac and supports frequencies from 50 Hz to 60 Hz, ensuring compatibility within European power standards. Its compact form factor of 32.6mm by 27.6mm by 24.3mm facilitates easy integration into circuit assemblies requiring limited space.

Notable features include a single primary winding combined with dual secondary windings delivering 42mA current per output. It is encapsulated with vacuum resin to enhance durability, prevent aging effects, and provide insulation exceeding 4000 volts for enhanced safety.

The unit is UL 94-V0 rated for non-flammable materials and complies with VDE 0551 and IEC 742 standards, underscoring its reliability and safety credentials. Weighing just 80 grams, it is optimized for through hole mounting, ensuring firm and reliable board integration.

Dual secondary outputs with nominal voltage of 18 V ac. Primary voltage: 230 V ac for European grade power sources. Compact dimensions suitable for PCB installations. 42mA transformer current with single primary and dual secondary winding type.

Encapsulated with vacuum resin to resist aging and enhance insulation. Compliance to UL 94-V0, VDE 0551, and IEC 742 standards. Maximum operating temperature of 70°C for safe operation under load. Through hole mount type for secure PCB assembly.

Manufactured in France ensuring European quality standards.

This Myrra PCB Transformer is ideal for industrial electronics, power supply units, laboratory equipment, telecommunications, and other commercial applications where reliable low-power transformers are essential. The 44095 model delivers dependable performance with superior insulation and quality construction.
