Digilent Development Kit Accessory Adapter 6002-410-006

Digilent 6002-410-006 is a Development Kit Accessory Adapter specifically designed for educational and prototyping applications with NI myDAQ and NI myRIO systems. This adapter provides a comprehensive platform that enables students and professionals to learn and test basic analog and digital circuits efficiently.

The adapter features a large 1260 tie point breadboard area which allows versatile and flexible circuit construction, essential for educational experimentation and prototyping. It includes onboard power regulators delivering 3.3 V and 5 V DC, ensuring a stable power supply for connected components and designs.

Included in the adapter are seven-segment LED displays for convenient digital output representation, four push buttons, and four slide switches enabling manual input control and testing options. Discrete LEDs assist in visualizing circuit states clearly during use.

The unit supports a power supply connector for standalone use, enhancing portability and flexibility in various setups. Connectivity is facilitated through the Mini System Port (MSP) connector, which links the Adapter with the myDAQ or myRIO devices, supplying power (+5 VDC and ±15 VDC) alongside eight configurable digital input/output pins, two analog inputs, and two analog outputs.

This combination offers a highly effective toolkit for teaching electronics, circuit design, and testing in industrial, educational, and laboratory environments. It is ideal for applications in STEM education, laboratory experiments, and developmental prototyping of analog and digital electronic circuits.

Designed for use with NI myDAQ and myRIO systems. Includes 1260 tie point breadboard area for versatile circuit building. Onboard 3.3 V and 5 V DC power regulators for stable power supply. Equipped with seven-segment LED displays for digital output visualization.

4 push buttons and 4 slide switches for user interaction. Discrete LEDs for status indication. Power supply connector provides standalone usage capability. Mini System Port (MSP) connector interface with power and I/O pins.

Eight configurable digital I/O pins, two analog inputs, and two analog outputs. Enables design, construction, and testing of analog and digital circuits. Explore more Development Tool Accessories at EnvMart for comprehensive electronics and STEM educational solutions.
