Eaton DR127-3R3-R Shielded Wirewound Surface Mount Inductor with Ferrite Core 3.3μH ±20% 21.5A IDC 125°C DR Series
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 8mm |
| Length | 12.5mm |
| Model | DR127-3R3-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 3.3μH |
| Standards/Approvals | RoHS |
| Package/Case | 0127 |
| Maximum DC Current | 21.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 5.67mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- This surface mount inductor offers reliable magnetic shielding for high efficiency.
- It is constructed with a wirewound design and a ferrite core for optimized performance.
- The inductor supports a maximum operating temperature of 125°C, suitable for demanding applications.
- It has a compact package size with a length and depth of 12.5mm and a height of 8mm.
- Its maximum DC resistance is 5.67 mΩ, ensuring minimal power loss.
- The component is RoHS compliant and offered with a reel packaging style for efficient handling.
- Designed for use in computers, DVD players, portable electronics, and DC-DC converters.
Product Description
Eaton DR127-3R3-R shielded wirewound surface mount inductor with ferrite core is engineered for high power density and efficiency with a maximum DC current of 21.5A and inductance of 3.3μH ±20%.
This magnetically shielded wirewound choke is part of the DR series, designed for surface mount applications requiring compact size and reliability with a 125°C maximum operating temperature.
The inductor's construction includes a molded ferrite core and a surface mount termination style, ensuring durability and excellent magnetic performance. It features a low DC resistance of 5.67mΩ and maintains performance across a wide temperature range from -40°C to 125°C.
Typical applications are in electronics including computers, DVD players, LCD panels, DC-DC converters, noise filtering, and resonant converters, providing noise suppression and power conversion efficiency.
Magnetically shielded wirewound construction for high power density. Ferrite core offering excellent magnetic properties and durability. Surface mount termination designed for compact PCB integration. Capable of handling 21.5A maximum DC current.
Operating temperature range from -40°C to 125°C for harsh environments. Low DC resistance minimizing power loss and heat generation. RoHS compliant, ensuring environmental safety standards. The inductor is supplied in reel packaging, facilitating automated assembly processes and efficient inventory management.
This product is manufactured in China and formerly branded under Cooper Bussmann, now Eaton, assuring quality and traceability. Explore the extensive range of Surface Mount Inductors at EnvMart for reliable electronic component selection.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 3.3μH with a tolerance of ±20%.
It can handle a maximum DC current of 21.5A.
The maximum operating temperature is 125°C, suitable for demanding applications.
The maximum DC resistance is 5.67 mΩ, which helps minimize power loss.
The dimensions are 12.5mm in length and depth, and 8mm in height.
It features a ferrite core, which provides excellent magnetic properties.
The termination style is surface mount, designed for compact PCB integration.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
The minimum operating temperature is -40°C, allowing it to function in harsh environments.
The maximum self-resonant frequency is 100kHz.
Typical applications include computers, DVD players, LCD panels, and DC-DC converters.
It is supplied in reel packaging, which facilitates automated assembly processes.
