Omron X Series Roller Plunger Limit Switch, SPDT Contact, Thermosetting Resin Housing, 10A 125V DC X-10GQ22-B
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Omron |
| Length | 49.2mm |
| Model | X-10GQ22-B |
| Depth | 17.45mm |
| IP Rating | IP00 |
| Width | 24.2mm |
| Housing Material | Thermosetting Resin |
| Series | X |
| Maximum Operating Temperature | 80°C |
| Mounting Orientation | Side |
| Contact Configuration | SPDT |
| Actuator Type | Roller Plunger |
| Contact Type | Snap Action |
| Minimum Operating Temperature | -25°C |
| Switching Current | 10A |
| Terminal type | Screw |
| Standards/Approvals | RoHS |
| Operating Force | 5N |
| Mechanical Life | 1000000Operations |
| Switching DC Voltage | 125V dc |
| Conduit Entry | 20 mm |
Key Features
- The actuator type is a roller plunger for precise mechanical operation.
- Snap action contact improves responsiveness and reliability.
- Rated IP00, suitable for controlled industrial environments.
- Supports a switching current capacity of 10 amperes.
- Equipped with screw type terminals for secure connections.
- Operates reliably in temperature ranges from -25°C to 80°C.
- Compact dimensions with length of 49.2mm, width of 24.2mm, and depth of 17.45mm.
- Designed for side mounting orientation with a mechanical life of up to 1,000,000 operations.
Product Description
Omron X-10GQ22-B Roller Plunger Limit Switch is a high-quality industrial switch designed for precise position sensing and control in automation and electrical systems. Featuring a thermosetting resin housing and snap action SPDT contacts, this device provides reliable switching for currents up to 10A at 125V DC. The roller plunger actuator ensures sensitive and accurate actuation over a mechanical life of one million operations.
The switch is rated IP00, which suits applications in clean, dry environments. It operates effectively over a wide temperature range from -25°C to 80°C, enabling robust performance in varied industrial settings including manufacturing automation, conveyor systems, and process control.
With compact dimensions (49.2mm length, 24.2mm width, 17.45mm depth) and a 20mm conduit entry, it supports easy integration and mounting on the side of equipment. Screw terminals facilitate secure wiring. Omron's magnetic blowout technology efficiently extinguishes generated electrical arcs, enhancing switch longevity and safety.
The actuator type is roller plunger for mechanical precision. SPDT snap action contact configuration enables reliable switching. Thermosetting resin housing offers durability and electrical insulation. Switching current capacity is 10 amperes at 125V DC.
Operating temperature range from -25°C to 80°C. Mechanical life rated at one million operations for extended service. Compact size allows integration in constrained spaces. Side mounting orientation and 20 mm conduit entry for versatile installation.
Manufactured in Japan, ensuring high-quality standards.
This limit switch is ideal for industrial automation, electrical panels, conveyor control, and position detection tasks. Its robust construction coupled with precise operation makes it a dependable choice for engineers and system integrators.
Explore our extensive range of Limit Switches and other high quality industrial automation components on EnvMart for reliable and efficient solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switching current capacity is 10 amperes at 125V DC.
It operates effectively within a temperature range of -25°C to 80°C.
This model uses a roller plunger actuator for precise mechanical operation.
The mechanical life is rated at up to one million operations.
The dimensions are 49.2mm in length, 24.2mm in width, and 17.45mm in depth.
It is designed for side mounting orientation.
It is equipped with screw type terminals for secure connections.
The switch has an IP rating of IP00, suitable for clean, dry environments.
The housing is made of thermosetting resin, providing electrical insulation.
It is ideal for industrial automation, electrical panels, conveyor control, and position detection tasks.
The contact configuration is SPDT (Single Pole Double Throw) with snap action contacts.
This limit switch is manufactured in Japan, ensuring high-quality standards.
