TE Connectivity AMPSEAL 16 Automotive Connector Male Black Cable 2 Way Crimp Termination 776427-1
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Colour | Black |
| Current | 13A |
| Height | 23.5mm |
| Model | 776427-1 |
| Depth | 36.75mm |
| IP Rating | IP67 |
| Width | 20.33mm |
| Gender | Male |
| Mount Type | Cable |
| Housing Material | Thermoplastic |
| Series | AMPSEAL 16 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Sub Type | Automotive Connector Housing |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Standards/Approvals | ELV, REACH, RoHS, UL 94HB |
| Number of Contacts | 2 |
| • Operating Temperature range | -40°C to +125°C |
| • Cable exit angle | 180° |
Key Features
- Designed for automotive wire-to-wire and wire-to-device connectivity.
- Rated for up to 13 amps current capacity per contact.
- Features IP67 waterproof rating for reliable operation in harsh environments.
- Operates in a temperature range from -40°C to +125°C.
- Constructed with durable thermoplastic housing material with black colour.
- Includes secure integral primary latch reinforcement and connector position assurance.
- Compatible with wire sizes from 2.18 to 3.67 mm diameter.
- Offers pitch spacing of 4.5 mm between contacts.
Product Description
TE Connectivity 776427-1 AMPSEAL 16 Automotive Connector Male black cable, featuring 2 way crimp termination, is engineered for high-reliability automotive and industrial applications. This connector series is designed to deliver secure wire-to-wire and wire-to-device interfaces with a robust construction and environmental sealing.
The AMPSEAL 16 series connectors allow current ratings up to 13 amps per contact, housed in a thermoplastic casing that withstands operating temperatures ranging from -40°C to 125°C. The IP67 rating certifies the connector for dust and water ingress protection, suitable for challenging environments including off-road, agricultural, and heavy-duty industrial equipment.
The 776427-1 model includes a two-contact male plug housing with integral primary latch reinforcement (PLR) and connector position assurance (CPA) to prevent accidental disconnections. It accommodates wire diameters from 2.18 to 3.67 mm using a crimp termination method, ensuring secure cable connection and robust performance.
The connector uses a 4.5 mm pitch for contacts and offers a 180° cable exit angle to facilitate effective cable routing in confined spaces. The black thermoplastic housing provides durability and resistance against physical and chemical stressors. This product complies with RoHS, ELV, REACH regulations and conforms to UL 94HB flammability standards.
This AMPSEAL 16 connector system is widely used in industrial, automotive, agricultural, and commercial vehicle sectors where rugged and reliable electrical connectivity is critical. It supports a range of configurations with 2, 3, 4, 6, 8, and 12-way options, making it versatile for multiple wiring needs.
Designed for automotive wire-to-wire and wire-to-device connectivity. Rated for up to 13 amps current capacity per contact. Features IP67 waterproof rating for reliable operation in harsh environments. Operates in a temperature range from -40°C to +125°C.
Constructed with durable thermoplastic housing material with black colour. Includes secure integral primary latch reinforcement and connector position assurance. Compatible with wire sizes from 2.18 to 3.67 mm diameter. Offers pitch spacing of 4.5 mm between contacts.
RoHS, ELV, REACH compliant, and UL 94HB rated. Cable exit angle is 180° for flexible cable routing.
For reliable performance parts and accessories designed for automotive electrical connectors, explore the AMPSEAL 16 series connectors at EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This automotive connector is rated for up to 13 amps current capacity per contact.
It features an IP67 waterproof rating, ensuring reliable operation in harsh environments.
The connector operates within a temperature range of -40°C to +125°C.
This connector uses a crimp termination method for secure cable connections.
The dimensions are 23.5 mm in height, 20.33 mm in width, and 36.75 mm in depth.
It is compatible with wire sizes ranging from 2.18 to 3.67 mm in diameter.
This model has 2 contacts.
It is constructed with durable thermoplastic housing material.
The cable exit angle is 180°, which facilitates effective cable routing in confined spaces.
This connector complies with RoHS, ELV, REACH regulations and conforms to UL 94HB flammability standards.
This connector belongs to the AMPSEAL 16 series.
It is widely used in industrial, automotive, agricultural, and commercial vehicle sectors for reliable electrical connectivity.
