TE Connectivity Rotary Coded DIP Switch Through Hole Slide Actuator Contact Resistance 50mΩ 1825002-9
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Mount Type | Through Hole |
| Actuator Type | Slide |
| Contact Resistance | 50mΩ |
Key Features
- Features through hole mount design ideal for PCB integration.
- Equipped with a slide actuator for easy operation and switching.
- Contact resistance rated at 50 milliohms ensuring reliable electrical connection.
- Gold flash plated contacts for enhanced corrosion resistance and durability.
- Black PPS housing providing mechanical stability and insulation.
- Suitable for aqueous or solvent cleaning due to high pressure wiping contact.
- Resistant to vapour phase reflow and wave soldering conditions for manufacturing robustness.
- Auto insertable design enhances assembly efficiency.
Product Description
TE Connectivity 1825002-9 Rotary Coded DIP Switch offers a reliable through hole mounting solution with slide actuator type and low contact resistance of 50mΩ, designed to meet rigorous industrial and electronic PCB assembly standards.
This switch belongs to the ADE and ADF series DIP switches featuring a compact 7.5 x 3.5mm footprint with a 2.54mm centerline spacing. Gold flash plated contacts provide superior electrical connectivity and corrosion resistance, enhancing product longevity.
The black PPS housing ensures mechanical strength and excellent insulation, suitable for demanding electrical and automation applications. The ADE series comes with extended slide actuators, while the ADF series has flush actuators, both featuring a high pressure contact system to withstand rigorous cleaning processes.
Designed for manufacturing efficiency, these DIP switches are auto insertable and withstand vapour phase reflow or wave soldering, accommodating modern electronic assembly techniques.
Through hole mount design optimizes PCB installation reliability. Slide actuator type facilitates user-friendly switch operation. 50mΩ contact resistance ensures minimal electrical loss. Gold flash plated contacts protect against corrosion and wear.
High pressure wiping contact supports aqueous and solvent cleaning methods. Durable black PPS housing provides strong insulation and mechanical protection. Supports vapour phase reflow and wave soldering for advanced manufacturing.
Auto insertable feature enhances assembly speed and accuracy.
Commonly applied in industrial automation, electronics manufacturing, control systems, and embedded device assemblies, this DIP switch exemplifies dependable switching performance with compact design.
Explore more options within the Rotary Coded DIP Switch category at EnvMart for comprehensive selection of switches meeting diverse application requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contact resistance of this model is rated at 50 milliohms, ensuring reliable electrical connectivity.
It features a through hole mount design, which is ideal for PCB integration.
This switch is equipped with a slide actuator, facilitating easy operation and switching.
The switch has a compact footprint of 7.5 x 3.5 mm with a 2.54 mm centerline spacing.
It features gold flash plated contacts for corrosion resistance and a black PPS housing for mechanical stability and insulation.
Yes, it supports high pressure wiping contact, making it suitable for aqueous or solvent cleaning methods.
Yes, it is resistant to vapour phase reflow and wave soldering conditions, accommodating modern electronic assembly techniques.
It is commonly applied in industrial automation, electronics manufacturing, control systems, and embedded device assemblies.
The auto insertable design enhances assembly speed and accuracy during the manufacturing process.
This model belongs to the ADE and ADF series of DIP switches, which differ in actuator design.
The country of origin for this switch is India.
Gold flash plating enhances electrical connectivity and provides corrosion resistance, contributing to the longevity of the switch.
