Murata Power Solutions Through Hole Pulse Transformer 1:1 Turns Ratio, 67μH Primary Inductance, 0.17Ω Primary 78601/4C

Murata Power Solutions 78601/4C Through Hole Pulse Transformer is engineered for high-performance electronic applications requiring precise signal transformation and isolation. This pulse transformer provides a 1:1 turns ratio with a primary inductance of 67μH and a low primary DC resistance of 0.17Ω, making it ideal for efficient energy transfer and minimal signal distortion in electrical circuits.

Designed with through-hole mounting, it features 6 pins that facilitate stable and reliable connection to circuit boards. The device maintains optimal functionality within a temperature range from 0°C to 70°C, suitable for various industrial and commercial environments.

Its compact dimensions of 9.52mm length, 9mm width, and 6.35mm depth allow for easy integration into space-constrained electronic assemblies. The leakage inductance is maintained at a low 0.19μH, ensuring excellent signal integrity and minimal interference, crucial for high-frequency switching applications.

This pulse transformer is RoHS certified, reflecting compliance with environmental regulations and quality manufacturing processes. The unit supports an isolation voltage of 1kV, providing necessary electrical protection in power supply circuits.

Common applications include general-purpose pulse transformers used in coupling circuits, thyristor or triac firing, and compact switch mode power supply designs. Additionally, by connecting windings in series, the standard turns ratios may be modified for customized electrical requirements. It can also serve effectively as a common mode choke in filtering roles.

This pulse transformer features a through-hole mount type suitable for PCB integration. It has a low primary DC resistance of 0.17Ω ensuring minimal power loss. The transformer operates reliably within 0°C to 70°C temperature range.

It includes 6 pins for secure electrical connections and supports an isolation voltage of 1kV. The compact design measures 9.52mm length, 9mm width, and 6.35mm depth. Leakage inductance is tightly controlled at 0.19μH for signal integrity.

The device weighs approximately 1.1g, facilitating lightweight PCB assemblies. RoHS compliant, ensuring environmental safety and quality standards. Commonly used in coupling circuits, thyristor/triac firing, and small-sized switch mode power supplies.

Suitable for industrial, laboratory, manufacturing, and power electronics applications, this Pulse Transformer exemplifies reliability and performance. Explore our extensive range of Transformers & Transformer Parts for complementary components to enhance your power supply designs. EnvMart offers specialized products ensuring quality and technical support for professionals.
