Phoenix Contact PTSM 0.5/5-2.5-H SMD R44 Series Horizontal 5-Contact PCB Terminal Block, 2.5 mm Pitch, 160 V, 6 A 1771059

Phoenix Contact 1771059 PTSM 0.5/5-2.5-H SMD R44 Series Horizontal PCB Terminal Block is a high-quality electronic connector designed for reliable low-profile wire-to-board interconnections. This model supports 5 contacts aligned horizontally on a single row with a precise 2.5 mm pitch, operating at a rated current of 6 A and up to 160 V voltage.

The terminal block housing is made from liquid crystal polymer, providing excellent thermal stability and a UL 94 V-0 inflammability rating, ensuring safe, robust operation in industrial and commercial electronic assemblies. Its compact design integrates seamlessly into SMT (Surface Mount Technology) production lines, enabling efficient and streamlined PCB assembly.

The spring-cage contact system allows a secure, tool-free connection of solid or stranded conductors up to 0.5 mm² cross-section. Users can release connected wires easily via a release button, boosting maintenance efficiency. Additional solder arms on the sides help reduce soldering pin mechanical stress, enhancing durability and solder joint reliability.

This terminal block is ideal for various applications in electronics manufacturing, measuring instruments, industrial automation, and power distribution systems requiring a compact, reliable PCB connection interface.

This PCB terminal block has five contacts arranged in one horizontal row. It features a 2.5 mm pitch suitable for compact PCB layouts. Rated for 6 A current at a voltage of 160 V. Constructed with a liquid crystal polymer housing for durability and stability.

The spring-cage design allows tool-free connection and release of 0.5 mm² conductors. Designed specifically for pure SMT soldering processes to reduce mechanical strain. Additional solder arms enhance mechanical strength during soldering and operation.

Compact, low-profile form factor saves PCB space without sacrificing current capacity.
