RS PRO PCB Terminal Block 5-Contact 5.08 mm Pitch Through Hole Mount 1 Row 10A Current 300V Voltage 146-8348

Free Delivery in India | Lowest Global Shipping Charges

RS PRO PCB Terminal Block 5-Contact 5.08 mm Pitch Through Hole Mount 1 Row 10A Current 300V Voltage 146-8348

Name: RS PRO PCB Terminal Block 5-Contact 5.08 mm Pitch Through Hole Mount 1 Row 10A Current 300V Voltage 146-8348
Brand: RS PRO
SKU: 214149



Category PCB Terminal Block Brand RS PRO Condition New

Specifications

Country of Origin	China
Voltage	300V
Brand	RS PRO
Colour	Green
Orientation	Vertical
Current	10A
Length	25.4mm
Model	146-8348
Depth	10.1mm
Width	8.3mm
Mount Type	Through Hole
Housing Material	Polyamide 66
Series	RS PRO
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS, cRUus approved
Number of Contacts	5
Minimum Wire Size mm²	0.13mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	26AWG
Maximum Wire Size AWG	16AWG

Key Features

Supports nominal current of 10 amperes with voltage rating of 300 volts.
Constructed with flame retardant polyamide 66 housing ensuring durability and safety.
Compatible with wire sizes from 0.13 mm² (26 AWG) up to 1.31 mm² (16 AWG).
Features captive screw terminals with rising clamp for secure connections.
Vertical orientation and green color for identifiable PCB integration.
Measures 25.4 mm length, 8.3 mm width, and 10.1 mm depth.
Complies with RoHS and cRUus standards for quality and safety.
Professional-grade terminal block suitable for industrial, electronic, and power connector applications.

Product Description

RS PRO 146-8348 PCB Terminal Block is a reliable 5-contact terminal block designed for through hole mounting on printed circuit boards. It features a 5.08 mm pitch and is manufactured with a flame retardant polyamide 66 housing to ensure enhanced safety and durability under electrical stress up to 300V and 10A current rating.

Its vertical orientation and green color aid in clear identification and integration within electronic assemblies. The terminal block supports wire sizes ranging from 0.13 mm² (26 AWG) to 1.31 mm² (16 AWG), optimized for secure connections via captive screw rising clamp terminals.

The compact dimensions measuring 25.4 mm in length, 8.3 mm in width, and 10.1 mm in depth make it suitable for various PCB layouts. Certified to meet RoHS directives and cRUus approvals, this product ensures compliance with industry standards for electronic components.

This terminal block features a 2-12 pole double interlocking mechanism that enhances mounting strength, providing stability in demanding industrial, laboratory, manufacturing, HVAC, and electrical power distribution applications. The 4-12 solid block end stackable design facilitates modular scalability of connection points.

Commonly used across electronics manufacturing, power connectors, and industrial automation, the RS PRO 146-8348 is designed to meet professional assembly needs and stringent quality requirements for long-term service.

Supports nominal current of 10 amperes with voltage rating of 300 volts. Constructed with flame retardant polyamide 66 housing ensuring durability and safety. Compatible with wire sizes from 0.13 mm² (26 AWG) up to 1.31 mm² (16 AWG).

Features captive screw terminals with rising clamp for secure connections. Vertical orientation and green color for identifiable PCB integration. Measures 25.4 mm length, 8.3 mm width, and 10.1 mm depth. Complies with RoHS and cRUus standards for quality and safety.

Professional-grade terminal block suitable for industrial, electronic, and power connector applications. Explore RS PRO category for more PCB Terminal Blocks and other power connectors at EnvMart.
