MEAN WELL IP67 Encapsulated AC-DC LED Driver, 36V, 241.2W, 6.7A Constant Voltage, 1 Output, 1/10 V Potentiometer Dimming,
Specifications
| Country of Origin | India |
|---|---|
| Brand | MEAN WELL |
| Model | IP67 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | HLG-240H |
| Configuration | Encapsulated |
| Sub Type | LED Driver |
| Operating Modes | Constant Voltage |
| Number of outputs | 1 |
| Terminal type | Wire |
| Maximum Output Power | 241.2W |
| Input Voltage | 264, 90, 127, 373V ac |
| Output Voltage | 36V |
| Power Dissipation | 241.2W |
| Standards/Approvals | UL, TUV, SELV, EN, CSA, CE, CB |
| Dimming Operation | 1/10 V, Potentiometer |
| Primary Type | AC-DC |
| Driver Current | 6.7A |
Key Features
- Compact panel mount LED driver suitable for indoor and outdoor applications.
- Offers 1/10V potentiometer dimming operation for flexible brightness control.
- Designed with short circuit, overload, over-voltage, and over-temperature protections.
- High efficiency and power factor correction compliant with EN 61000-3-2.
- Conforms to multiple safety and quality standards including UL, TUV, CE, CSA, and EN approvals.
- Equipped with 300mm un-terminated input and output wire leads for easy installations.
- Ideal for LED lighting and moving sign applications requiring reliable constant voltage supply.
- Robust IP67 rated housing for enhanced environmental protection.
Product Description
MEAN WELL HLG-240H-36B is a high-performance encapsulated AC-DC LED driver with IP67 protection rating, delivering a regulated 36V output at a maximum power of 241.2W and a continuous current of 6.7A. This driver provides constant voltage operation suitable for a wide range of LED lighting and moving sign applications both indoors and outdoors.
The unit features a robust panel mount design and comes with 300mm un-terminated input and output leads to facilitate easy installation. It offers a 1/10V potentiometer dimming function, enabling precise and flexible brightness control for LED fixtures.
Built with multiple protection mechanisms including short circuit, overload, over-voltage, and over-temperature protection, the driver ensures safe and reliable operation in demanding industrial environments. The design incorporates power factor correction compliant with EN 61000-3-2 and meets EMC requirements EN 55022 Class B, minimizing electromagnetic interference.
Certified to international safety standards such as UL1012, EN61347-1, EN61347-2-13, UL60950-1, TUV EN60950-1, and carrying approvals from UL, TUV, SELV, EN, CSA, CE, and CB, this driver assures compliance and quality.
The product is ideal for industrial LED lighting installations where dependable constant voltage power and high environmental resistance are necessary. Long service life is supported by an MTBF rating according to MIL-HDBK-217F specifications.
IP67 encapsulated, panel mount LED driver with 1 output. Output voltage of 36V and maximum output power of 241.2W. Continuous driver current of 6.7A with constant voltage operation. 1/10V potentiometer dimming operation allows precise brightness adjustment.
Comprehensive protections: short circuit, overload, over-voltage, and temperature. High power factor and EMC compliant to EN and IEC standards. Suitable for LED lighting and moving sign applications. Robust construction designed for indoor and outdoor installation environments.
Includes 300mm un-terminated input and output wires for flexible installation. Meets multiple international safety approvals ensuring quality and reliability. Explore MEAN WELL LED Drivers and power supplies in EnvMart’s Electronics & Electricals category for high-quality, trusted components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this LED driver is 241.2W.
This model provides a regulated output voltage of 36V.
It can deliver a continuous driver current of 6.7A.
It supports 1/10V potentiometer dimming for flexible brightness control.
The input voltage range for this driver is 90-264V AC.
It includes protections against short circuit, overload, over-voltage, and over-temperature.
This unit is designed for panel mounting.
It comes with 300mm un-terminated input and output wire leads for installation.
It conforms to multiple safety standards including UL, TUV, CE, CSA, and EN approvals.
It is suitable for LED lighting and moving sign applications requiring a constant voltage supply.
The country of origin for this LED driver is India.
