Preci-Dip 833 Series Straight Surface PCB Socket, 20-Contact, 2 Row, 2 mm Pitch, 150V, 12A, Black Glass 833-87-020-10-001101

Preci-Dip 833-87-020-10-001101 is a high-quality straight surface mount PCB socket designed for board-to-board connections. Featuring 20 female contacts arranged in two rows with a precise 2 mm pitch, this socket is engineered to ensure reliable and secure electrical connections in various demanding environments.

The socket housing is made from black glass filled polyester, offering excellent durability and resistance to mechanical stress. The contacts are composed of beryllium copper alloy plated with a gold flash to guard against corrosion and wear, providing consistent performance over extended use.

Its electrical ratings include a voltage capacity of 150V and a current rating of 12A, making it suitable for a range of electronic applications. The maximum operating temperature is rated at 125°C, accommodating high-temperature operating conditions.

The product features a pin length of 3.2 mm optimized for mating pins within 0.4 to 0.66 mm diameter, facilitating efficient soldering and connectivity on PCB boards. It meets the UL 94V-0 standard for flame retardance, underscoring its compliance with safety and industry requirements.

This Preci-Dip PCB socket is manufactured in Switzerland, reflecting precision engineering and quality manufacturing processes. It is ideal for use in industrial electronics, manufacturing assembly, and other applications requiring stable, high-performance PCB socket connections.

Constructed with black glass filled polyester housing for enhanced durability. Features 20 female contacts arranged in 2 rows for efficient connection. Rated for 150V voltage and 12A current capacity ensuring reliable electrical performance.

Contact material consists of beryllium copper alloy with gold flash plating for corrosion resistance. Designed for surface mount with straight orientation to facilitate PCB assembly. Maximum operating temperature is 125°C suitable for demanding environments.

Pin length of 3.2 mm suitable for mating pins between 0.4 mm to 0.66 mm diameter. Compliant with UL 94V-0 flammability standard for safety assurance. Manufactured in Switzerland with high precision standards. Ideal for industrial and electronic applications requiring stable PCB connections.

Explore more PCB Sockets and connectors on EnvMart to find compatible components and enhance your electronic assembly processes.
