Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector, 7 Contacts, 2.54 mm Pitch, 1 Row 811-S1-007-10-015101

Preci-Dip 811-S1-007-10-015101 Spring Loaded Connector is a high-quality, shrouded, straight through hole connector designed for robust and reliable PCB connections. Featuring 7 gold-plated brass contacts with a 2.54 mm pitch in a single row, this connector offers excellent electrical performance and durability.

The connector housing is made from fibreglass reinforced polyethylene terephthalate, providing high mechanical strength and resistance to environmental stress. With a current rating of 3.5 A and voltage rating of 150 V, it supports demanding electrical requirements in electronic manufacturing and testing.

Its temperature operating range spans from -55°C to 125°C, ensuring performance in extreme thermal environments. The through-hole mount type provides secure mechanical attachment to printed circuit boards, while the shrouded design offers protection for the contacts and prevents accidental damage or short circuits.

The spring-loaded contacts ensure low resistance and maintain reliable multipoint electrical connections even under vibration or movement, enhancing the connector’s stability and service life. This connector is ideal for use in industrial electronics, laboratory instrumentation, telecommunications, and other precision electronic equipment applications.

Features a 2.54 mm pitch for standard spacing compatibility. Seven gold-plated brass contacts provide excellent conductivity. Fibreglass reinforced polyethylene terephthalate housing for durability. Designed with through-hole mounting for secure PCB installation.

Shrouded design protects contacts and prevents damage. Operates reliably from -55°C to 125°C temperature range. Rated for 3.5 A current at up to 150 V maximum voltage. Single row, straight orientation maximizes board space usage.

Ideal for electronic component, testing, and industrial applications. Manufactured in Switzerland ensuring quality and precision. Explore the full range of Preci-Dip Connectors and related electronic components at EnvMart for your design and manufacturing needs.
