Preci-Dip 833 Series Right Angle PCB Socket 20-Contact 2 Row 2 mm Pitch Solder Termination 150V 12A 833-87-020-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 833 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket features black glass filled polyester housing for durability.
- Designed with a right angle orientation for PCB mounting.
- Contacts are made of beryllium copper alloy with gold flash plating.
- Supports a maximum operating temperature of 125°C.
- Offers a row pitch and contact pitch of 2 mm for precise alignment.
- Compatible with mating pins of diameter 0.4 to 0.66 mm or 0.5 mm square.
- Connects using board-to-board system with female contact gender.
- Mount type is PCB through-hole soldering for secure attachment.
Product Description
Preci-Dip 833-87-020-20-001101 Right Angle PCB Socket is a high-quality electronic component designed for reliable board-to-board connections. This socket features 20 contacts arranged in 2 rows with a 2 mm pitch suitable for mounting on printed circuit boards.
The housing is made from black glass filled polyester providing excellent durability and resistance in electronic applications. Its right angle orientation supports compact and efficient PCB assembly. The contact material is beryllium copper alloy with gold flash plating, ensuring excellent electrical conductivity and corrosion resistance.
Rated for a voltage of 150V and current of 12A, this PCB socket can safely operate up to a maximum temperature of 125°C, making it suitable for demanding industrial and commercial electronics environments. The unit is compatible with pins ranging from 0.4 mm to 0.66 mm diameter or 0.5 mm square pins, offering versatility in various connector assemblies.
The solder termination and through-hole PCB mount type ensure a robust mechanical and electrical connection, ideal for applications requiring high reliability such as industrial automation, instrumentation, and telecommunications equipment. The product conforms to UL 94V-0 flammability standards and carries the quality assurance of Swiss manufacturing.
The socket includes 20 female contacts arranged in 2 rows. 2 mm pitch and row pitch for precise PCB integration. Black glass filled polyester housing ensures durability and insulation. Beryllium copper alloy contacts with gold flash plating for conductivity and corrosion resistance.
Rated for 150V and 12A, ideal for medium power electronic connections. Right angle orientation for space-efficient PCB layouts. Through-hole solder mount for secure and long-lasting installation. Maximum operating temperature of 125°C suits harsh environments.
Swiss origin ensures premium build quality and reliability.
Choose the Preci-Dip 833 Series PCB Socket for your electronic assembly needs to ensure robust, high-performance connections in industrial and commercial applications. Explore more components within the PCB Sockets category at EnvMart for comprehensive electronic solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PCB socket is rated for a maximum voltage of 150V and a current of 12A.
This model can safely operate at a maximum temperature of 125°C.
The housing is made of black glass filled polyester, while the contacts are made of beryllium copper alloy with gold flash plating.
It features 20 female contacts arranged in 2 rows with a pitch of 2 mm.
This socket utilizes solder termination for secure attachment to the PCB.
This socket is designed with a right angle orientation for PCB mounting.
It is compatible with mating pins of diameter 0.4 mm to 0.66 mm or 0.5 mm square pins.
The mount type is through-hole soldering, ensuring a robust connection.
This model is suitable for applications in industrial automation, instrumentation, and telecommunications equipment.
It conforms to UL 94V-0 flammability standards, indicating its safety in electronic applications.
The socket is manufactured in Switzerland, ensuring high build quality.
The connector system type is board-to-board, designed for reliable connections between PCBs.
