RS PRO PCB Terminal Block, 2-Contact, 5.08 mm Pitch, Through Hole Mount, Vertical Orientation, 300V, 20A, Polyamide 146-8343
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Green |
| Orientation | Vertical |
| Current | 20A |
| Length | 10.16mm |
| Model | 146-8343 |
| Depth | 18mm |
| Width | 10.6mm |
| Mount Type | Through Hole |
| Housing Material | Polyamide 66 |
| Series | RS PRO |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS, cRUus approved |
| Number of Contacts | 2 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 3.3mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 12AWG |
| RS PRO PCB Terminal Block, 2-Contact, 5.08 mm Pitch, Through Hole, 1 RowBrand | RS PRO |
Key Features
- Provides a current rating of 20A for reliable power connections.
- Features a high-quality polyamide 66 housing with UL94-V0 flame retardant rating.
- Suitable for wire sizes ranging from 0.05 mm² (30 AWG) to 3.3 mm² (12 AWG).
- Compact dimensions of approximately 10.16 mm length, 10.6 mm width, and 18 mm depth enable space-saving PCB design.
- The connector is RoHS and cRUus approved, ensuring compliance with industry standards.
Product Description
RS PRO 146-8343 PCB Terminal Block is a high-quality electrical component manufactured for industrial, electronics, and manufacturing applications. Designed with a 2-contact configuration and a 5.08 mm pitch, it is ideal for use on printed circuit boards requiring reliable terminal connections.
The terminal block supports a current rating up to 20A and a voltage rating of 300V, making it suitable for power distribution and control circuits. It accommodates wire sizes from 0.05 mm² to 3.3 mm² (30 AWG to 12 AWG), facilitating versatile wiring options for various industrial tasks.
Constructed with a robust polyamide 66 housing, it meets UL94-V0 flame retardant standards, ensuring enhanced safety in high-temperature environments. Its through-hole mount type and vertical orientation simplify PCB assembly and integration into complex electronic systems.
This product is RoHS compliant and cRUus approved, reflecting adherence to global environmental and safety standards. The compact dimensions of 10.16 mm length, 10.6 mm width, and 18 mm depth allow efficient use of PCB real estate while maintaining secure electrical connections.
Current rating of 20A supports robust power connections. Polyamide 66 housing provides durable, flame-retardant construction. Wire size compatibility from 0.05 mm² to 3.3 mm² enhances installation flexibility. Through-hole mount and vertical orientation for reliable PCB mounting.
RoHS compliant and cRUus approved for quality assurance.
This RS PRO PCB terminal block series is widely used in industrial control panels, electrical distribution systems, and manufacturing equipment. It offers engineers and technicians a dependable solution for PCB wiring and terminal connections. Explore more RS PRO industrial electrical components and connectors at EnvMart.
Explore more products in our PCB Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 20A, making it suitable for reliable power connections.
The voltage rating for this terminal block is 300V, suitable for power distribution and control circuits.
The dimensions are approximately 10.16 mm in length, 10.6 mm in width, and 18 mm in depth.
It features a through-hole mount type, which simplifies PCB assembly and integration.
The housing is made of polyamide 66, which is flame-retardant with a UL94-V0 rating.
This model has a vertical orientation, facilitating its use in various PCB designs.
Yes, it is RoHS compliant and cRUus approved, ensuring adherence to environmental and safety standards.
It has a 2-contact configuration, making it suitable for various applications in industrial electronics.
The pitch of this terminal block is 5.08 mm, which is standard for many PCB applications.
The country of origin for this terminal block is China.
