RS PRO PCB Terminal Block, 10-Contact, 5.08 mm Pitch, Through Hole Mount, Polyamide 66 Housing, 300V, 10A, Vertical 146-8350

RS PRO 146-8350 is a high-quality PCB terminal block designed for electronic and electrical power connection applications requiring 10 contacts with a 5.08 mm pitch. Its through hole mounting approach provides a secure and reliable connection on printed circuit boards used in various industrial and commercial electronics.

The terminal block housing is made from Polyamide 66, a flame retardant material compliant with UL94-V0 standards, ensuring enhanced safety and durability during operation. It supports currents up to 10A and voltages up to 300V, suitable for a wide range of low to medium power electronics and control systems.

This single row, vertical orientation terminal block accepts wire sizes ranging from 0.13 mm² to 1.31 mm² (26 to 16 AWG), providing versatile connectivity options for different wiring requirements. Its green color aids visual differentiation in electronic assemblies.

Designed and certified to meet RoHS and cRUus specifications, it confirms compliance with environmental and safety regulations essential for modern electronics manufacturing.

Physical dimensions include a length of 50.8 mm, width of 8.3 mm, and depth of 10.1 mm, ensuring compact footprint on PCB designs. The terminal block features rising clamp professional terminals with captive screws and guided pin alignment to facilitate easy installation and robust electrical contact.

This component is ideal for use in industrial manufacturing, power distribution boards, electronic devices assembly, telecommunication equipment, and other commercial electronic systems where secure and standardized PCB connection solutions are required. Its sturdy build and certified features assist engineers in meeting design and safety criteria efficiently.

Constructed with durable Polyamide 66 housing for flame retardancy. Supports current rating of 10A and voltage of 300V for reliable operation. Compatible with wire sizes from 0.13mm² (26 AWG) up to 1.31mm² (16 AWG). Vertical orientation with single row design optimizes space on PCB.

Approved to RoHS and cRUus standards ensuring compliance and safety. Green color coded for easy identification in assemblies. Length measures 50.8 mm with width of 8.3 mm and depth of 10.1 mm.
