RS PRO PCB Terminal Block, 10-Contact, 5.08 mm Pitch, Through Hole Mount, 1 Row, Polyamide 66 Housing 146-8265

Free Delivery in India | Lowest Global Shipping Charges

RS PRO PCB Terminal Block, 10-Contact, 5.08 mm Pitch, Through Hole Mount, 1 Row, Polyamide 66 Housing 146-8265

Name: RS PRO PCB Terminal Block, 10-Contact, 5.08 mm Pitch, Through Hole Mount, 1 Row, Polyamide 66 Housing 146-8265
Brand: RS PRO
SKU: 214122



Category PCB Terminal Blocks Brand RS PRO Condition New

Specifications

Country of Origin	China
Voltage	300V
Brand	RS PRO
Colour	Green
Orientation	Vertical
Current	10A
Length	50.8mm
Model	146-8265
Depth	10.1mm
Width	8.3mm
Mount Type	Through Hole
Housing Material	Polyamide 66
Series	RS PRO
Number of Rows	1
Pitch	5.08mm
Standards/Approvals	RoHS, cRUus approved
Number of Contacts	10
Minimum Wire Size mm²	0.13mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	26AWG
Maximum Wire Size AWG	16AWG

Key Features

Features professional rising clamp terminals suitable for 0.13 to 1.31 mm² wire sizes.
Constructed with polyamide 66 housing providing UL94-V0 flame retardant protection.
Designed for through hole mounting with a vertical orientation ensuring stable installation.
Supports a maximum current of 10A and voltage rating of 300V for safe operation.
Includes guided pin alignment and captive screws for ease of assembly and secure fitting.
Compact dimensions measure 50.8 mm length, 8.3 mm width, and 10.1 mm depth.
Meets RoHS compliance and cRUus approvals ensuring quality and regulatory standards.

Product Description

RS PRO 146-8265 PCB Terminal Block is a robust component designed for secure electrical connections in various electronic, industrial, and manufacturing applications. Featuring 10 contact points spaced at a 5.08 mm pitch, this terminal block facilitates precise wiring with professional rising clamp terminals capable of accommodating wire sizes from 0.13 mm² to 1.31 mm² (26 AWG to 16 AWG).

The housing is constructed from polyamide 66 which is UL94-V0 flame retardant rated, ensuring safety in typical operating environments. Its through hole mounting type and vertical orientation support easy and permanent installation on printed circuit boards. The terminal block carries up to 10 amperes of current at a nominal voltage of 300 volts, meeting typical power requirements for control and signal circuit connections.

Additional design features include a guided pin alignment that simplifies assembly and captive screws that maintain secure wire connections over time. Compact dimensions of 50.8 mm length, 8.3 mm width, and 10.1 mm depth make it suitable for PCB layouts where space optimization is critical.

This RS PRO product complies with RoHS directives and holds cRUus approvals, reflecting its adherence to safety and environmental standards. Manufactured in China, it is part of the trusted RS PRO series known for quality and reliability.

This PCB terminal block is ideal for use in industrial machines, electronics manufacturing, automation systems, and electrical devices requiring stable and durable electrical connections on PCBs.

Features professional rising clamp terminals suitable for 0.13 to 1.31 mm² wire sizes. Constructed with polyamide 66 housing providing UL94-V0 flame retardant protection. Designed for through hole mounting with a vertical orientation ensuring stable installation.

Supports a maximum current of 10A and voltage rating of 300V for safe operation. Includes guided pin alignment and captive screws for ease of assembly and secure fitting. Compact dimensions measure 50.8 mm length, 8.3 mm width, and 10.1 mm depth.

Meets RoHS compliance and cRUus approvals ensuring quality and regulatory standards. Explore a broad range of RS PRO electrical components and PCB Terminal Blocks on EnvMart for comprehensive industrial and electronics assembly solutions.
