Texas Instruments 8-Bit Non-Inverting LVTTL Bus Transceiver, 24-Pin SSOP, Surface Mount, 2.7V to 5.5V SN74LVC4245ADBR

The Texas Instruments SN74LVC4245ADBR bus transceiver is an 8-bit non-inverting LVTTL device housed in a 24-pin SSOP surface mount package. It forms part of the 74LVC family utilizing silicon gate CMOS technology optimized for low-voltage operation ranging from 2.7V to 5.5V, offering significant power savings compared to traditional 5V systems.

This transceiver supports bidirectional data communication with 8 independent channels and features a 3-state output type for advanced bus control. Its LVTTL input/output levels are compatible with standard TTL and LVCMOS logic families, facilitating easy integration into mixed-signal designs.

With a maximum propagation delay of 6.7ns at capacitive loads, this device ensures high-speed data transfer suitable for various industrial and electronic equipment applications. The device operates reliably within a wide temperature range from -40°C to 85°C, making it suitable for demanding environments.

Physical dimensions of the IC measure 8.2mm in length and 1.95mm in height allowing for compact designs on printed circuit boards. The package type is SSOP, designed to support surface mounting with superior mechanical stability.

Robustness is further enhanced through latch-up immunity exceeding 250mA as per JESD standards and ESD protection beyond JESD 22 guidelines, ensuring longevity and dependable operation in industrial, laboratory, instrumentation, and commercial electronic manufacturing contexts.

This bus transceiver supports input compatibility with LVTTL/TTL and outputs compliant with LVCMOS standards, making it versatile for a variety of electronic designs requiring low-voltage operation and efficient power consumption.

Operates from 2.7V to 5.5V supply voltage range. 8 non-inverting channels facilitate bidirectional data transmission. Compact 24-pin SSOP surface mount package. Propagation delay time of 6.7ns supports high-speed operation.

Wide operating temperature range from -40°C to 85°C. Maximum output currents: -24mA (high level), 24mA (low level). Latch-up immunity and ESD protection exceed industry standards. Compatible with LVTTL/TTL inputs and LVCMOS outputs.

Ideal for electronic components, power connectors, semiconductors, and logic IC applications.

For advanced design and manufacturing needs, this bus transceiver offers precise and reliable performance adhering to Texas Instruments high-quality standards. Explore more products in the Bus Transceivers category at EnvMart for complete semiconductor solutions.
