Renesas Electronics DC Input 4-Channel Photocoupler, Surface Mount, 16-Pin SSOP PS2802-4-V-F3-A

Renesas Electronics PS2802-4-V-F3-A is a high-performance DC input photocoupler device, featuring four optically coupled channels in a compact 16-pin SSOP surface mount package. It integrates a gallium arsenide (GaAs) light emitting diode and an NPN silicon Darlington photo transistor, designed for high-density electronic applications requiring reliable electrical isolation.

This component provides a maximum forward voltage of 1.4 volts and operates with a DC input current up to 5mA. The typical rise and fall times of 200 microseconds enable fast switching ideal for industrial and electronic systems. It maintains performance integrity across a wide operating temperature range from -55°C to 100°C, making it suitable for challenging environmental conditions.

Its high isolation voltage rating of 2.5kVrms ensures excellent protection of sensitive circuits against high voltages. The logic output capability combined with a maximum current transfer ratio of 2000% enhances signal fidelity and reliability in control and signal processing applications.

Package type is a small and thin SSOP, facilitating high density mounting in compact electronic devices. The device is UL approved and manufactured as a lead-free product aligning with RoHS compliance and safety standards. It is delivered in tape and reel packaging to support efficient automated assembly lines.

Applications for the PS2802-4-V-F3-A photocoupler cover electronic circuits in industrial automation, telecommunications, power supply isolation, and signal interfacing in various industrial, commercial, and laboratory equipment. Its compact footprint and robust electrical characteristics make it ideal for modern high-performance electronic designs.

The device contains four optically isolated channels for reliable signal isolation. Maximum forward voltage is rated at 1.4 volts ensuring efficient operation. Input current type is DC with a maximum input current of 5mA.

Typical rise and fall times are 200 microseconds for fast switching performance. Operating temperature range is wide, from -55°C to 100°C suitable for harsh environments. The device provides high isolation voltage of 2.5kVrms for enhanced circuit protection.

Package is a small, thin SSOP type optimized for space-saving layouts. The photocoupler features a logic output and a high current transfer ratio of up to 2000%. Complies with UL standards and is a lead-free product, supporting environmental regulations.

Packaging is tape and reel, facilitating automated assembly processes. Explore more Renesas Electronics components and similar advanced optoelectronic devices on EnvMart.
